R&S ZPH
Der R&S ZPH Cable-Rider ist ein 1-Tor Kabel- und Antennen-Analysator der mit allen wesentlichen Basismessfunktionen für die Installation und den Service von Antennen ausgestattet ist. Das einfach zu bedienende Gerät mit Touchscreen und großem Tastaturblock eignet sich sehr gut für den Ausseneinsatz.
- Frequenzbereich von 2 MHz bis 3 GHz / 4 GHz, Erweiterung mittels Keycode
- Kabelfehlstellen-, Reflexionsdämpfungs-, VSWR-, und Eintor-Kabeldämpfungsmessung
- Ideal für den Feldeinsatz: 9 Stunden Akkulaufzeit, 2,5 kg, beleuchtetes Tastenfeld
- Combi Modell (.12) mit 2 MHz bis 3 GHz (CAT mode); 5 kHz bis 3 GHz/ 4 GHz (Spektrum Analysator Mode)
- S21 Messung bei ZPH Combi Modell (.12)
- schnelle Bootzeit, reflexionsfreies Display, robustes Gehäuse (IP51)
Alle Listenpreise finden Sie unter Geräte & Optionen sowie Zubehör
Modell | Bezeichnung | R&S Bestellnr. | Preis (€) zuzügl. MwSt | Preis (€) inkl. MwSt |
---|---|---|---|---|
ZPH | Cable Rider Handheld Kabel- und Antennen Analysator (.02) 2 MHz bis 3 GHz (optional bis 4 GHz erweiterbar) | 1321.1211.02 | 4.290,00 € | 5.105,10 € |
ZPH (.52) | Cable Rider Handheld Kabel- und Antennen Analysator (.02) 2 MHz bis 3 GHz (optional bis 4 GHz erweiterbar) | 1321.1211.52 | 4.540,00 € | 5.402,60 € |
ZPH | Cable Rider Handheld Kabel- und Antennen Analysator Combi Modell (.12), 2 MHz bis 3 GHz (CAT mode) und 5 kHz bis 3 GHz (Spektrum Analysator Mode) mit BiasTee und Mitlaufgenerator, 2 Port Transmissions-Messungen (optional bis 4 GHz erweiterbar) | 1321.1211.12 | 6.790,00 € | 8.080,10 € |
ZPH-P1 | Cable Rider Handheld Kabel- und Antennen Analysator 2 MHz bis 3 GHz (optional bis 4 GHz erweiterbar) | 1321.1211P01 | 4.170,00 € | 4.962,30 € |
ZPH-P2 | Cable Rider Handheld Kabel- und Antennen Analysator 2 MHz bis 4 GHz (inkl. ZPH-B4 Freq.-Upgrade auf 4 GHz) | 1321.1211P02 | 4.900,00 € | 5.831,00 € |
ZPH-P3SA | Cable Rider Handheld Kabel- und Antennen Analysator Combi Modell, 2 MHz bis 3 GHz (CAT mode) und 5 kHz bis 3 GHz (Spektrum Analysator Mode) mit BiasTee und Mitlaufgenerator, 2 Port Transmissions-Messungen Paket Cable Rider ZPH (2-ports) Package (3 GHz) Inkl. serialisiertes Produkt: Cable Rider ZPH 1321.1211K12 bestehend aus: Cable Rider ZPH, 2MHz - 3GHz (optional bis 4 GHz erweiterbar) | 1321.1211P03 | 6.590,00 € | 7.842,10 € |
ZPH-P4SA | Cable Rider Handheld Kabel- und Antennen Analysator Combi Modell 2 MHz bis 4 GHz (CAT mode) und 5 kHz bis 4 GHz (Spektrum Analysator Mode) mit BiasTee und Mitlaufgenerator, 2 Port Transmissions-Messungen | 1321.1211P04 | 7.410,00 € | 8.817,90 € |
ZPH-ANR4 | Cable Rider Handheld Kabel- und Antennen Analysator 2 MHz bis 4 GHz One Port N(f) inkl. Frequenzerweiterung -B4 inkl. ZPH-B10 GPS Support | 1321.1211P61 | 5.460,00 € | 6.497,40 € |
ZPH-FOX4 | Cable Rider Handheld Kabel- und Antennen Analysator Combi Modell .12 Zweitor-Modell, 2 MHz bis 4 GHz mit BiasTee und Mitlaufgenerator, 2 Port Transmissions-Messungen N(f) inkl. ZPH-B4 Freq.-Upgrade auf 4 GHz inkl. ZPH-B22 Preamplifier inkl. ZPH-K1 Spectrum Analysis | 1321.1211P62 | 10.710,00 € | 12.744,90 € |
ZPH-AA1 | Paket Cable Rider ZPH T&M Kit für RF Vision Antenna alignment bundle: Inkl. serialisiertes Produkt: Cable Rider ZPH 1321.1211K02 bestehend aus: Cable Rider ZPH, ZPH-B4 Frequenz-Upgrade 3 GHz auf 4 GHz, ZN-Z103 Kalibrier-Einheit, HA-Z321 Koffer für Handhelds und Zubehör, HA-Z322 wasserabweisendes Trageholster | 1321.1211P81 | 6.960,00 € | 8.282,40 € |
ZPH-AA2 | Paket Cable Rider ZPH Combi Analyzer T&M Kit für RF Vision Antenna alignment bundle: Inkl. serialisiertes Produkt: Cable Rider ZPH 1321.1211K12 bestehend aus Cable Rider ZPH Combi Modell, ZPH-B4 Frequenz-Upgrade 3 GHz auf 4 GHz, ZPH-K1 Spectrumanalyse Messungen Applikation, ZN-Z103 Kalibrier-Einheit, HA-Z321 Koffer für Handhelds und Zubehör, HA-Z322 Wasserabweisendes Trageholster | 1321.1211P82 | 12.320,00 € | 14.660,80 € |
ZPH-COM1 | ZPH Cable Rider Handheld Kabel- und Antennen Analyzer (.02) ZPH-B4 Frequenz-Upgrade, 3 GHz auf 4 GHz ZPH-B10 GPS-Unterstützung ZPH-K9 Power Sensor Support ZPH-K19 Channel Power Meter ZPH-K29 Pulse Measurements with Power Sensor | 1321.1211P98 | 7.540,00 € | 8.972,60 € |
ZPH-COM2 | ZPH Cable Rider Handheld Combi model & Spektrumanalysator (.12) ZPH-B4 Frequency Upgrade, 3 GHz to 4 GHz ZPH-B22 Preamplifier ZPH-K1 Spectrum analysis measurement application ZPH-K15 Interference Analysis ZPH-K16 Signal Strength Mapping Measurement Application ZPH-K7 Modulation Analysis ZPH-K9 Power Sensor Support ZPH-K19 Channel Power Meter ZPH-K29 Pulse Measurements with Power Sensor Promotion: Today´s solution for tomorrow´s challenge | 1321.1211P99 | 11.350,00 € | 13.506,50 € |
ZPH-K105 | EMF measurement application (unregistrierte Lizenz) (Link: Application Note als pdf-Datei) | 1334.7207.03 | 1.980,00 € | 2.356,20 € |
Software Optionen | ||||
ZPH-B4 | Frequenz-Upgrade, 3 GHz auf 4 GHz (Software Lizenz) | 1321.0380.02 | 850,00 € | 1.011,50 € |
ZPH-B4 | Frequenz-Upgrade, 3 GHz auf 4 GHz (unregistrierte Lizenz) | 1321.0380.03 | 850,00 € | 1.011,50 € |
ZPH-B10 | GPS-Unterstützung nur für Model .02 (Software Lizenz) | 1321.0396.02 | 315,00 € | 374,85 € |
ZPH-B10 | GPS-Unterstützung nur für Model .02 (unregistrierte Lizenz) | 1321.0396.03 | 315,00 € | 374,85 € |
ZPH-B22 | Spectrum Analyzer Preamplifier (erfordert ZPH-K1), (nur für Modell .12) (Software Lizenz) | 1334.5627.02 | 430,00 € | 511,70 € |
ZPH-B22 | Spectrum Analyzer Preamplifier (erfordert ZPH-K1), (nur für Modell .12) (unregistrierte Lizenz) | 1334.5627.03 | 430,00 € | 511,70 € |
ZPH-K1 | Spectrum Analysis Measurement Application (nur für Modell .12) (Software Lizenz) | 1334.5604.02 | 2.790,00 € | 3.320,10 € |
ZPH-K1 | Spectrum Analysis Measurement Application (nur für Modell .12) (unregistrierte Lizenz) | 1334.5604.03 | 2.790,00 € | 3.320,10 € |
ZPH-K7 | Modulation Analysis AM/FM/ASK/FSK ( erfordert ZPH-K1), (nur für Modell .12) (Software Lizenz) | 1334.5633.02 | 620,00 € | 737,80 € |
ZPH-K7 | Modulation Analysis AM/FM/ASK/FSK ( erfordert ZPH-K1), (nur für Modell .12) (unregistrierte Lizenz) | 1334.5633.03 | 620,00 € | 737,80 € |
ZPH-K9 | Messungen mit Leistungsmessköpfen (Software Lizenz) | 1321.0415.02 | 535,00 € | 636,65 € |
ZPH-K9 | Messungen mit Leistungsmessköpfen (unregistrierte Lizenz) | 1321.0415.03 | 535,00 € | 636,65 € |
ZPH-K15 | Interference Analysis (erfordert ZPH-K1), (nur für Modell .12) (Software Lizenz) | 1334.5640.02 | 1.180,00 € | 1.404,20 € |
ZPH-K15 | Interference Analysis (erfordert ZPH-K1), (nur für Modell .12) (unregistrierte Lizenz) | 1334.5640.03 | 1.180,00 € | 1.404,20 € |
ZPH-K16 | Signal Strength Mapping Measurement Application (erfordert ZPH-K1), (nur für Modell .12) (Software Lizenz) | 1334.5656.02 | 1.180,00 € | 1.404,20 € |
ZPH-K16 | Signal Strength Mapping Measurement Application (erfordert ZPH-K1), (nur für Modell .12) (unregistrierte Lizenz) | 1334.5656.03 | 1.180,00 € | 1.404,20 € |
ZPH-K19 | Kanal-Leistungsmesser (Software Lizenz) | 1321.0409.02 | 690,00 € | 821,10 € |
ZPH-K19 | Kanal-Leistungsmesser (unregistrierte Lizenz) | 1321.0409.03 | 690,00 € | 821,10 € |
ZPH-K29 | Pulsmessungen mit Power Sensor (Software Lizenz) | 1321.0421.02 | 1.160,00 € | 1.380,40 € |
ZPH-K29 | Pulsmessungen mit Power Sensor (unregistrierte Lizenz) | 1321.0421.03 | 1.160,00 € | 1.380,40 € |
ZPH-K43 | Applikation Messempfänger und Channel-Scan (ZPH-K1 erforderlich) (unregistrierte Lizenz) | 1334.5662.03 | Auf Anfrage | |
ZPH-K45 | Vektor-Voltmeter Messungen Applikation (Software-Lizenz) | 1334.5679.02 | Auf Anfrage | |
ZPH-K57 | Erweiterte Gated Trigger Messungen: - Adjacent Channel Leakage Power Ratio (ACLR) - Occupied Bandwidth (OBW) - Spectrum Emission Mask (SEM) (Software-Lizenz) | 1334.5685.02 | 600,00 € | 714,00 € |
Infos zu Gewährleistungsverlängerung und Gerätekalibrierung finden Sie unter "Serviceoptionen" Wir erstellen Ihnen gerne ein detailiertes Angebot | ||||
Preise Stand 2024-04-01 - Preisirrtum vorbehalten - Es gelten die Preise aus unseren Angeboten |
Modell | Bezeichnung | R&S Bestellnr. | Preis (€) zuzügl. MwSt | Preis (€) inkl. MwSt |
---|---|---|---|---|
Messleitungen (N-, BNC-, Interface-Kabel) | ||||
FSH-Z144 | USB-Adapterkabel (USB-Stecker auf Binder-Stecker) für FSH-Z14/ FSH-Z44 Durchgangs-Leistungsmessköpfe zum Anschluß an den FSH/ ZVH/ ZPH Handheld-Analysator, Länge 1,8 m | 1145.5909.02 | 165,00 € | 196,35 € |
TSEMF-CV | Konverterkabel | 1158.9250.02 | Auf Anfrage | |
FSH-Z320 | HF-Kabel, Länge: 1 m, N-Stecker/N-Buchse für Option FSH-K41, bis 8 GHz | 1309.6600.00 | 275,00 € | 327,25 € |
FSH-Z321 | HF-Kabel, Länge: 3 m, N-Stecker/N-Buchse für Option FSH-K41, bis 8 GHz | 1309.6617.00 | 365,00 € | 434,35 € |
HE300USB | Serial an USB Adapter zum Anschluss des HE300-, HE400- oder HL300-Steuerkabels an einen USB Port. Länge ca. 30cm USB Typ A Stecker - Binder 7 pol. Subminiatur-Buchse | 4080.9440.02 | 320,00 € | 380,80 € |
HA-Z211 | Ersatz-USB-Kabel | 1309.6169.00 | 36,00 € | 42,84 € |
HA-Z210 | Ersatz-LAN-Kabel | 1309.6152.00 | 27,00 € | 32,13 € |
NRP-ZKU | USB Interface Kabel für NRP-Messköpfe, L= 1.5 m (für NRPxxS/T/A/SN/TN/AN) - Messkopfbetrieb am Laptop/PC; Stromversorgung über USB . Stecker: M12(sensorseitig) - USB A | 1419.0658.03 | 227,00 € | 270,13 € |
NRP-ZKC | USB Leistungsmesskopfkabel L=0,75m für NRPxxS/T/A/SN/TN/AN Messkopfbetrieb Stromversorgung über USB, Stecker: M12(sensorseitig) - USB-C | 1425.2442.02 | 227,00 € | 270,13 € |
NRP-ZKC | USB Leistungsmesskopfkabel L=1,5m für NRPxxS/T/A/SN/TN/AN Messkopfbetrieb Stromversorgung über USB, Stecker: M12(sensorseitig) - USB-C | 1425.2442.03 | 248,00 € | 295,12 € |
NRP-ZKC | USB Leistungsmesskopfkabel L=3,0m für NRPxxS/T/A/SN/TN/AN Messkopfbetrieb Stromversorgung über USB, Stecker: M12(sensorseitig) - USB-C | 1425.2442.04 | 289,00 € | 343,91 € |
NRP-Z4 | USB-Adapter Kabel (passiv), Länge 2 m , zum Anschluss von NRP-Z211 und NRP-Z221 Leistungsmessköpfen z.B. an ZVH, SMB100B, ZPH, etc. | 1146.8001.02 | 227,00 € | 270,13 € |
Adapter | ||||
Adapter | Adapter N (m) – BNC (f) | 0118.2812.00 | Auf Anfrage | |
Adapter | Adapter N (m) – N (m) | 0092.6581.00 | Auf Anfrage | |
Adapter | Adapter N (m) – SMA (f) | 4012.5837.00 | Auf Anfrage | |
Adapter | Adapter N (m) – 7/16 (f) | 3530.6646.00 | Auf Anfrage | |
Adapter | Adapter N (m) – 7/16 (m) | 3530.6630.00 | Auf Anfrage | |
Adapter | Adapter N (m) – FME (f) | 4048.9790.00 | Auf Anfrage | |
Adapter | Adapter BNC (m) – Banana (f) | 0017.6742.00 | Auf Anfrage | |
Anpassglieder | ||||
RAZ | Anpassglied 50/75 Ohm, 0 - 2700 MHz, zur einseitigen Anpassung, N-Anschlüsse (Link: Details als pdf-Datei) | 0358.5714.02 | 960,00 € | 1.142,40 € |
RAM | Anpassglied 50/75 Ohm, 0 - 2700 MHz, zur beidseitigen Anpassung, N-Anschlüsse (Link: Details als pdf-Datei) | 0358.5414.02 | 960,00 € | 1.142,40 € |
FSH-Z38 | Anpassglied, 50 Ω/75 Ω, bidirektional, 0 Hz bis 1 GHz, BNC-Buchse/N-Stecker, Belastbarkeit 1 W | 1300.7740.02 | 350,00 € | 416,50 € |
Dämpfungsglieder | ||||
RDL50 | Leistungsdämpfungsglied, 50 W, 20 dB, 50 Ω, DC bis 6 GHz, N(f) – N(m) | 1035.1700.52 | 1.180,00 € | 1.404,20 € |
RBU100 | Leistungsdämpfungsglied, 100 W, 3 dB, 50 Ω, DC bis 2 GHz, N(f) – N(m) | 1073.8495.03 | 2.820,00 € | 3.355,80 € |
RBU100 | Leistungsdämpfungsglied, 100 W, 6 dB, 50 Ω, DC bis 2 GHz, N(f) – N(m) | 1073.8495.06 | 2.820,00 € | 3.355,80 € |
RBU100 | Leistungsdämpfungsglied, 100 W, 10 dB, 50 Ω, DC bis 2 GHz, N(f) – N(m) | 1073.8495.10 | 2.820,00 € | 3.355,80 € |
RBU100 | Leistungsdämpfungsglied, 100 W, 20 dB, 50 Ω, DC bis 2 GHz, N(f) – N(m) | 1073.8495.20 | 2.820,00 € | 3.355,80 € |
RBU100 | Leistungsdämpfungsglied, 100 W, 30 dB, 50 Ω, DC bis 2 GHz, N(f) – N(m) | 1073.8495.30 | 2.820,00 € | 3.355,80 € |
Kalibriereinheit | ||||
FSH-Z29 | Kalibrierstandards Leerlauf/ Kurzschluss/ 50 Ohm-Abschluss kombiniert, zur Kalibrierung der VSWR- und DTF-Messung, DC bis 3,6 GHz | 1300.7510.03 | 610,00 € | 725,90 € |
Batterie Packs / Ladegeräte | ||||
HA-Z301 | Ersatznetzteil, einschließlich Netzstecker für EU, GB, US, AUS, CH (für z.B. FPH) | 1321.1386.02 | 195,00 € | 232,05 € |
HA-Z302 | Car Adpater | 1321.1340.02 | 140,00 € | 166,60 € |
HA-Z303 | Ladegerät für Lithium-Ionen Akku HA-Z306 | 1321.1328.02 | 375,00 € | 446,25 € |
HA-Z306 | Lithium-Ionen Akku Pack, 6,4 Ah | 1321.1334.02 | 345,00 € | 410,55 € |
Taschen / Koffer | ||||
RTH-Z4 | Hartschalen-Transportkoffer (für RTH, FPH, ZPH, ZNH) | 1326.2774.02 | 260,00 € | 309,40 € |
HA-Z220 | Tragetasche B×H×T: 260 ×360×280 mm (für ZPH, FPH, RTH, FSH, ZNH, ZVH) | 1309.6175.00 | 330,00 € | 392,70 € |
HA-Z321 | Transportkoffer für Handhelds mit Zubehör (für ZPH, FPH, FSH, ZNH, ZVH) (Bild) | 1321.1357.02 | 435,00 € | 517,65 € |
HA-Z322 (.02) | Trageholster (wasserabweisend) für Handheldgeräte FPH, ZPH, ZNH | 1321.1370.02 | 350,00 € | 416,50 € |
HA-Z322 (.03) | Regensicheres Trageholster Handheldgeräte für FPH, ZPH, ZNH | 1321.1370.03 | 390,00 € | 464,10 € |
FSH-Z36 | Kopfhörer FSC, FSH3/6/18, FSH4/8, ZPH etc | 1145.5838.02 | 35,70 € | 42,48 € |
weiteres Messgerätezubehör: Messleitungen, Adapter, etc. | ||||
Coax-Kabel | Testline N auf N Coax-Kabel Länge: 0,6 m (Link: Datenblatt (pdf)) | auf Anfrage | ||
Coax-Kabel | Testline N auf N Coax-Kabel Länge: 1 m (Link: Datenblatt (pdf)) | auf Anfrage | ||
Coax-Kabel | Testline N auf N Coax-Kabel Länge: 6 m (Link: Datenblatt (pdf)) | auf Anfrage | ||
Coax-Kabel | Testline Coax-Kabel mit verschiedenen Steckern und Längen (Link: Datenblatt (pdf)) | Auf Anfrage | ||
Adapter | N auf SMA | 18,00 € | 21,42 € | |
Adapter | BNC auf N | 12,00 € | 14,28 € | |
Adapter | BNC auf SMA | 12,00 € | 14,28 € | |
Infos zu Gewährleistungsverlängerung und Gerätekalibrierung finden Sie unter "Serviceoptionen" Wir erstellen Ihnen gerne ein detailiertes Angebot | ||||
Preise Stand 2024-04-01 - Preisirrtum vorbehalten - Es gelten die Preise aus unseren Angeboten |
Modell | Bezeichnung | R&S Bestellnr. | Preis (€) zuzügl. MwSt | Preis (€) inkl. MwSt |
---|---|---|---|---|
Link: Details zu Leistungsmessköpfen | ||||
NRP-Z81 | 1 nW bis 100 mW, 50 MHz bis 18 GHz | 1137.9009.02 | Auf Anfrage | |
NRP-Z85 | 1 nW bis 100 mW, 50 MHz bis 40 GHz, (2,92 mm) | 1411.7501.02 | Auf Anfrage | |
NRP-Z86 | 1 nW bis 100 mW, 50 MHz bis 40 GHz, (2,40 mm) | 1417.0109.40 | Auf Anfrage | |
NRP-Z86 | 1 nW bis 100 mW, 50 MHz bis 44 GHz (2,40 mm) | 1417.0109.44 | Auf Anfrage | |
Mittelwert-Leistungs-Messköpfe | ||||
NRP6A | 100 pW bis 200 mW, 8 kHz bis 6 GHz | 1424.6796.02 | Auf Anfrage | |
NRP18A | 100 pW bis 200 mW, 8 kHz bis 18 GHz Average Leistungsmesskopf benötigt USB Sensor-Kabel NRP-ZKU oder Messkopfkabel NRP-ZK6 Gerät ist abgekündigt, aktuellen Preis bitte anfragen | 1424.6815.02 | 5.730,00 € | 6.818,70 € |
Zweipfad-Dioden Leistungs-Messköpfe | ||||
NRP-Z211 | 10 MHz bis 8 GHz, 100 mW, 2 Pfade | 1417.0409.02 | 3.120,00 € | 3.712,80 € |
NRP-Z211 | 10 MHz bis 8 GHz, 1 nW bis 100mW, N(m) mit verkürztem Kabel 0,4m>/strong> für universelle Anwendungen | 1417.0409.04 | 3.120,00 € | 3.712,80 € |
NRP-Z221 | 10 MHz bis 18 GHz, 100 mW, 2 Pfade | 1417.0309.02 | 4.050,00 € | 4.819,50 € |
Dreipfad-Dioden Leistungs-Messköpfe | ||||
NRP8S | 100 pW bis 200 mW, 10 MHz bis 8 GHz | 1419.0006.02 | 4.481,00 € | 5.332,39 € |
NRP18S | 100 pW bis 200 mW, 10 MHz bis 18 GHz | 1419.0029.02 | 5.367,00 € | 6.386,73 € |
NRP33S | 100 pW bis 200 mW, 10 MHz bis 33 GHz 3-Pfad Dioden Leistungsmesskopf | 1419.0064.02 | Auf Anfrage | |
NRP40S | 100 pW bis 200 mW, 50 MHz bis 40 GHz | 1419.0041.02 | Auf Anfrage | |
NRP50S | 100 pW bis 200 mW, 50 MHz bis 50 GHz | 1419.0087.02 | Auf Anfrage | |
Thermische Leistungs-Messköpfe | ||||
NRP18T | 300 nW bis 100 mW, DC bis 18 GHz | 1424.6115.02 | 3.657,00 € | 4.351,83 € |
NRP33T | 300 nW bis 100 mW, DC bis 33 GHz | 1424.6138.02 | Auf Anfrage | |
NRP40T | 300 nW bis 100 mW, DC bis 40 GHz | 1424.6150.02 | Auf Anfrage | |
NRP50T | 300 nW bis 100 mW, DC bis 50 GHz | 1424.6173.02 | Auf Anfrage | |
NRP67T | 300 nW bis 100 mW, DC bis 67 GHz | 1424.6196.02 | Auf Anfrage | |
NRP110T | 300 nW bis 100 mW, DC bis 110 GHz | 1424.6215.02 | Auf Anfrage | |
NRP18P | Puls-Leistungsmesskopf 50MHz bis 18GHz; 1nW bis 100mW, N (m) benötigt USB Sensor-Kabel NRP-ZKU oder Messkopfkabel NRP-ZK6 | 1444.1190.02 | 9.044,00 € | 10.762,36 € |
NRP-Zxx /Für NRPZxxx Leistungsmessköpfe ist zusätzlich das NRP-Z4 USB-Adapter Kabel erforderlich | ||||
FSH-Z14 | Durchgangsleistungsmesskopf, 30 mW bis 300 mW, 25 MHz bis 1 GHz | 1444.0029.02 | 3.626,00 € | 4.314,94 € |
FSH-Z44 | Durchgangsleistungsmesskopf, 30 mW bis 300 W, 200 MHz bis 4 GHz | 1444.0035.02 | 3.410,00 € | 4.057,90 € |
Optische Leistungsmessköpfe und Zubehör | ||||
HA-Z360 | Optischer OEM-USB-Leistungsmesser (Germanium) | 1334.5162.00 | 425,00 € | 505,75 € |
HA-Z361 | Optischer OEM-USB-Leistungsmesser (gefiltertes InGaAs) | 1334.5179.00 | 515,00 € | 612,85 € |
HA-Z362 | SC-Adapter für optischen Leistungsmesser | 1334.5185.00 | 75,00 € | 89,25 € |
HA-Z363 | LC-Adapter für optischen Leistungsmesser | 1334.5191.00 | 75,00 € | 89,25 € |
HA-Z364 | 2,5 mm Universal-Adapter für optischen Leistungsmesser | 1334.5204.00 | 57,00 € | 67,83 € |
HA-Z365 | 1,25 mm Universal-Adapter für optischen Leistungsmesser | 1334.5210.00 | 57,00 € | 67,83 € |
HA-Z366 | Patchkabel SC-LC SM, SX, Länge: 1 m | 1334.5227.00 | 45,00 € | 53,55 € |
HA-Z367 | Patchkabel SC-SC SM, SX, Länge: 1 m | 1334.5233.00 | 45,00 € | 53,55 € |
Infos zu Gewährleistungsverlängerung und Gerätekalibrierung finden Sie unter "Serviceoptionen" Wir erstellen Ihnen gerne ein detailiertes Angebot | ||||
Preise Stand 2024-04-01 - Preisirrtum vorbehalten - Es gelten die Preise aus unseren Angeboten |
Modell | Bezeichnung | R&S Bestellnr. | Preis (€) zuzügl. MwSt | Preis (€) inkl. MwSt |
---|---|---|---|---|
EMV Nahfeldsonden | ||||
HZ540 | EMV Nahfeldsondensatz 3 GHz, bestehend aus: aktiven HZ551 E-Feld-, HZ552 H-Feld-, HZ553 Hochimpedanz-Sonden, 1x SMA-N Kabel 1,2m abgekündigt, Verfügbarkeit anfragen | 3594.4196.02 | ||
HZ-15 | Compact Probe Set HZ15 passive E- und H- Feldsonden 30 MHz bis 3 GHz | 1147.2736.02 | 2.400,00 € | 2.856,00 € |
HZ-17 | Sondensatz für H-Nahfeldmessungen (passive Sonden) | 1339.4141.02 | 1.100,00 € | 1.309,00 € |
HZ-16 | Vorverstärker 100 kHz bis 3 GHz, 20 dB, Netzadapter 100 V bis 230 V für Sondensatz HZ-15 | 1147.2720.02 | 690,00 € | 821,10 € |
Antennen und Antennenzubehör | ||||
HA-Z1900 | Yagi Antenna, 1710 MHz to 1990 MHz | 1328.6825.02 | 865,00 € | 1.029,35 € |
HA-Z900 | Yagi Antenna, 824 MHz to 960 MHz | 1328.6283.02 | 865,00 € | 1.029,35 € |
HA-Z901 | RF Cable (length: 1 m), DC to 6 GHz, N male/N male connectors | 3626.2757.02 | 115,00 € | 136,85 € |
HA-Z902 | Tragetasche, für HA-Z900 oder HA-Z1900 Yagi-Antenne | 1328.6883.02 | 425,00 € | 505,75 € |
HE400PKUWB | Tragbare Richtantenne - Paket Inkl. serialisiertes Produkt+Optionen: HE400 Tragbare Richtantenne 4104.6000K02 bestehend aus: - HE400 Antennengriff für HE400 - HE400-K Kabelsatz - HE400UWB UWB Antennenmodul, 30 MHz bis 6 GHz | 4104.6000P02 | 5.875,00 € | 6.991,25 € |
HE400PKUWC | Tragbare Richtantenne mit Koffer -Paket Inkl. serialisiertes Produkt+Optionen: HE400 Tragbare Richtantenne 4104.6000K02 bestehend aus: - HE400 Antennengriff für HE400 - HE400-K Kabelsatz - HE400UWB UWB Antennenmodul 30 MHz bis 6 GHz - HE400Z1 Transportkoffer für HE400 | 4104.6000P03 | 6.620,00 € | 7.877,80 € |
HE400BCPKU | Tragbare Richtantenne (Basisversion) Inkl. serialisiertes Produkt+Optionen: HE400BC Tragbare Richtantenne 4104.6000K04 bestehend aus: - HE400BC Antennengriff für HE400BC - HE400-KB Kabelsatz - HE400UWB UWB Antennenmodul 30 MHz bis 6 GHz | 4104.6000P04 | 3.355,00 € | 3.992,45 € |
HE800-PA | Tragbare Richtantenne 18 GHz bis 44 GHz mit Vorverstärker | 4115.6006.02 | 5.520,00 € | 6.568,80 € |
HE800Z1 | Transportkoffer für HE800-PA und HE800-DC30 | 4115.7660.02 | 500,00 € | 595,00 € |
HE400-K | Kabelsatz für HE400BC (erfordert HE300USB) | 4104.7770.02 | Auf Anfrage | |
HE400HF | HF-Antennenmodul für HE400, 8,3 kHz bis 30 MHz | 4104.8002.02 | Auf Anfrage | |
HE400VHF | VHF-Antennenmodul für HE400, 20 MHz bis 200 MHz | 4104.8202.02 | Auf Anfrage | |
HE400UWB | UBB-Antennenmodul für HE400, 30 MHz bis 6 GHz | 4104.6900.02 | Auf Anfrage | |
HE400LP | Logarithmisch-periodisches Antennenmodul für HE400, 450 MHz bis 8 GHz | 4104.8402.02 | Auf Anfrage | |
HE400CEL | Mobilfunk-Antennenmodul für HE400, 700 MHz bis 2500 MHz | 4104.7306.02 | Auf Anfrage | |
HE400SCB | S/C band antenna module, 1.7 GHz to 6 GHz | 4104.7606.02 | Auf Anfrage | |
HE400SHF | SHF antenna module, 5 GHz to 20 GHz | 4104.8602.02 | Auf Anfrage | |
HA-Z350 | Logarithmisch-periodische OEM-Antenne, 700 MHz bis 4 GHz | 1321.1405.02 | 1.070,00 € | 1.273,30 € |
TS-EMF | Tragbares EMVU-Messsystem, Transportkoffer | 1158.9295.05 | Auf Anfrage | |
TSEMF-B1 | Isotrope Antenne, 30 MHz bis 3 GHz für TS-EMF | 1074.5719.02 | Auf Anfrage | |
TSEMF-B2 | Isotrope Antenne, 700 MHz bis 6 GHz für TS-EMF | 1074.5702.02 | Auf Anfrage | |
TSEMF-B3 | Isotrope Antenne, 9 kHz bis 200 MHz für TS-EMF | 1074.5690.02 | Auf Anfrage | |
Infos zu Gewährleistungsverlängerung und Gerätekalibrierung finden Sie unter "Serviceoptionen" Wir erstellen Ihnen gerne ein detailiertes Angebot | ||||
Preise Stand 2024-04-01 - Preisirrtum vorbehalten - Es gelten die Preise aus unseren Angeboten |
Features & Operation
Manuale | ||||
ZPH | Cable Rider Handheld Kabel- und Antennenanalysator | Manual pdf 9 MB |
||
ZPH ZND | Health Guide - For vector network analyzers gives advice to prevent electrical and mechanical damage | Flyer pdf 1 MB |
||
Fact-Sheets | ||||
ZPH | Cable Rider Handheld Kabel- und Antennenanalysator | Fact-Sheet pdf 1 MB |
||
Applikationen | ||||
ZPH | GPS-Bundle One-port cable and antenna analyzer with GPS support | pdf download | ||
FSH, FPH, ZVH, ZPH, HE400 | Fast 5G NR – interference hunting in the uplink of TDD networks | pdf download | ||
FPH, ZPH | EMF measurement application for frequency selective measurements Option -K105 | pdf download | ||
Firmware | ||||
ZPH | Firmware | ext. Link R&S Website: ZPH Firmware Download |
||
Gerätetreiber | ||||
ZPH | folgt in Kürze | |||
Software | ||||
InstrumentView MobileView | InstrumentView (PC-Software), MobileView (iOS/ Android-App) Kostenlose Software für Oszilloskope RTA4000, RTM3000, RTB2000, RTC1000, RTH, Spektrumanalysatoren FPC, FSC, FSH, FPH, ZPH, ZVH, Netzwerkanalysatoren ZNH | Software Details | ||
RSCommander | kostenloses Software-Tool für Spektrum-/ Netzwerkanalysatoren, Signalgeneratoren, Oszilloskope von Rohde & Schwarz. | Software Details |
Modell | Bezeichnung | R&S Bestellnr. | für Gerätetyp | für Geräte Art.-Nr. | Preis (€) zuzügl. MwSt | Preis (€) inkl. MwSt |
---|---|---|---|---|---|---|
Preise Stand 2023-03-01 - Preisirrtum vorbehalten - Kalibrierpreise & weitere Service-Optionen bitte immer anfragen. Wir erstellen Ihnen gerne ein detailiertes Angebot Es gelten die Preise aus unseren Angeboten | ||||||
WE1ZPH | Extension of the 3 year standard product warranty to 4 years for ZPH: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair | 3597.0640S02 | ZPH | 1321.1211.02 | 366,00 € | 435,54 € |
WE1ZPH | Extension of the 3 year standard product warranty to 4 years for ZPH: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair | 3598.2446S02 | ZPH | 1321.1211.12 | 516,00 € | 614,04 € |
WE2ZPH | Extension of the 3 year standard product warranty to 5 years for ZPH: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair | 3597.0640S03 | ZPH | 1321.1211.02 | 697,00 € | 829,43 € |
WE2ZPH | Extension of the 3 year standard product warranty to 5 years for ZPH: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair | 3598.2446S03 | ZPH | 1321.1211.12 | 983,00 € | 1.169,77 € |
CW1ZPH | Extension of the 3 year standard product warranty to 4 years and Calibration Coverage for ZPH for 4 years: - 3 scheduled R&S®Manufacturer- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Manufacturer-Calibrations after repair or option upgrade | 3597.0640S06 | ZPH | 1321.1211.02 | 938,00 € | 1.116,22 € |
CW1ZPH | Extension of the 3 year standard product warranty to 4 years and Calibration Coverage for ZPH for 4 years: - 3 scheduled R&S®Manufacturer- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Manufacturer-Calibrations after repair or option upgrade | 3598.2446S06 | ZPH | 1321.1211.12 | 1.378,00 € | 1.639,82 € |
CW2ZPH | Extension of the 3 year standard product warranty to 5 years and Calibration Coverage for ZPH for 5 years: - 4 scheduled R&S®Manufacturer- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Manufacturer-Calibrations after repair or option upgrade | 3597.0640S07 | ZPH | 1321.1211.02 | 1.450,00 € | 1.725,50 € |
CW2ZPH | Extension of the 3 year standard product warranty to 5 years and Calibration Coverage for ZPH for 5 years: - 4 scheduled R&S®Manufacturer- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Manufacturer-Calibrations after repair or option upgrade | 3598.2446S07 | ZPH | 1321.1211.12 | 2.118,00 € | 2.520,42 € |
AW1ZPH | Extension of the 3 year standard product warranty to 4 years and Accredited Calibration Coverage for ZPH for 4 years: - 3 scheduled R&S®Accredited- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Accredited-Calibrations after repair or option upgrade | 3597.0640S14 | ZPH | 1321.1211.02 | 1.158,00 € | 1.378,02 € |
AW1ZPH | Extension of the 3 year standard product warranty to 4 years and Accredited Calibration Coverage for ZPH for 4 years: - 3 scheduled R&S®Accredited- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Accredited-Calibrations after repair or option upgrade | 3598.2446S14 | ZPH | 1321.1211.12 | 1.819,00 € | 2.164,61 € |
AW2ZPH | Extension of the 3 year standard product warranty to 5 years and Accredited Calibration Coverage for ZPH for 5 years: - 4 scheduled R&S®Accredited- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Accredited-Calibrations after repair or option upgrade | 3597.0640S15 | ZPH | 1321.1211.02 | 1.750,00 € | 2.082,50 € |
AW2ZPH | Extension of the 3 year standard product warranty to 5 years and Accredited Calibration Coverage for ZPH for 5 years: - 4 scheduled R&S®Accredited- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Accredited-Calibrations after repair or option upgrade | 3598.2446S15 | ZPH | 1321.1211.12 | 2.569,00 € | 3.057,11 € |
ACAZPH | R&S®Accredited Calibration for ZPH: - Akkreditiertes Kalibrierzertifikat - Akkreditiert nach ISO 17025, ISO 9001 zertifiziert, rückführbar auf nationale/ internationale Standards - Verifizierung vollständiger Produkt- spezifikation nach Verfahren wie bei der Herstellung, inklusive Angabe von Messunsicherheiten/Guardbanding | 3597.0640.03 | ZPH | 394,00 € | 468,86 € | |
ACAZPH | R&S®Accredited Calibration for ZPH: - Akkreditiertes Kalibrierzertifikat - Akkreditiert nach IEC/ISO 17025, ISO 9001 zertifiziert, rückführbar auf nationale/internationale Standards - Verifizierung vollständiger Produktspezikifationen nach Hersteller-Verfahren; nicht binäre Entscheidungsregel mit Angabe von Messunsicherheiten/Guardbanding wird angewendet (ILAC-G8) - Kalibrierergebnisse bei Anlieferung | 3597.1975.03 | ZPH | 435,00 € | 517,65 € | |
ACAZPH | R&S®Accredited Calibration for ZPH: - Akkreditiertes Kalibrierzertifikat - Akkreditiert nach IEC/ISO 17025, ISO 9001 zertifiziert, rückführbar auf nationale/internationale Standards - Verifizierung vollständiger Produktspezikifationen nach Hersteller-Verfahren; nicht binäre Entscheidungsregel mit Angabe von Messunsicherheiten/Guardbanding wird angewendet (ILAC-G8) - Kalibrierergebnisse bei Anlieferung | 3598.2446.03 | ZPH | 655,00 € | 779,45 € |
-
Alle Listenpreise finden Sie unter Geräte & Optionen sowie Zubehör
- Geräte & Optionen
-
Modell Bezeichnung R&S Bestellnr. Preis (€)
zuzügl. MwStPreis (€)
inkl. MwStZPH Cable Rider Handheld Kabel- und Antennen Analysator (.02)
2 MHz bis 3 GHz (optional bis 4 GHz erweiterbar)1321.1211.02 4.290,00 € 5.105,10 € ZPH (.52) Cable Rider Handheld Kabel- und Antennen Analysator (.02)
2 MHz bis 3 GHz (optional bis 4 GHz erweiterbar)1321.1211.52 4.540,00 € 5.402,60 € ZPH Cable Rider Handheld Kabel- und Antennen Analysator Combi Modell (.12), 2 MHz bis 3 GHz (CAT mode) und 5 kHz bis 3 GHz (Spektrum Analysator Mode) mit BiasTee und Mitlaufgenerator, 2 Port Transmissions-Messungen
(optional bis 4 GHz erweiterbar)1321.1211.12 6.790,00 € 8.080,10 € ZPH-P1 Cable Rider Handheld Kabel- und Antennen Analysator
2 MHz bis 3 GHz (optional bis 4 GHz erweiterbar)1321.1211P01 4.170,00 € 4.962,30 € ZPH-P2 Cable Rider Handheld Kabel- und Antennen Analysator
2 MHz bis 4 GHz (inkl. ZPH-B4 Freq.-Upgrade auf 4 GHz)1321.1211P02 4.900,00 € 5.831,00 € ZPH-P3SA Cable Rider Handheld Kabel- und Antennen Analysator Combi Modell, 2 MHz bis 3 GHz (CAT mode) und 5 kHz bis 3 GHz (Spektrum Analysator Mode) mit BiasTee und Mitlaufgenerator, 2 Port Transmissions-Messungen
Paket Cable Rider ZPH (2-ports) Package (3 GHz) Inkl. serialisiertes Produkt:
Cable Rider ZPH 1321.1211K12 bestehend aus: Cable Rider ZPH, 2MHz - 3GHz
(optional bis 4 GHz erweiterbar)1321.1211P03 6.590,00 € 7.842,10 € ZPH-P4SA Cable Rider Handheld Kabel- und Antennen Analysator Combi Modell 2 MHz bis 4 GHz (CAT mode) und 5 kHz bis 4 GHz (Spektrum Analysator Mode) mit BiasTee und Mitlaufgenerator, 2 Port Transmissions-Messungen 1321.1211P04 7.410,00 € 8.817,90 € ZPH-ANR4 Cable Rider Handheld Kabel- und Antennen Analysator 2 MHz bis 4 GHz One Port N(f) inkl. Frequenzerweiterung -B4
inkl. ZPH-B10 GPS Support1321.1211P61 5.460,00 € 6.497,40 € ZPH-FOX4 Cable Rider Handheld Kabel- und Antennen Analysator Combi Modell .12 Zweitor-Modell, 2 MHz bis 4 GHz mit BiasTee und Mitlaufgenerator, 2 Port Transmissions-Messungen N(f)
inkl. ZPH-B4 Freq.-Upgrade auf 4 GHz
inkl. ZPH-B22 Preamplifier
inkl. ZPH-K1 Spectrum Analysis1321.1211P62 10.710,00 € 12.744,90 € ZPH-AA1 Paket Cable Rider ZPH T&M Kit für RF Vision Antenna alignment bundle:
Inkl. serialisiertes Produkt: Cable Rider ZPH 1321.1211K02
bestehend aus: Cable Rider ZPH, ZPH-B4 Frequenz-Upgrade 3 GHz auf 4 GHz, ZN-Z103 Kalibrier-Einheit, HA-Z321 Koffer für Handhelds und Zubehör, HA-Z322 wasserabweisendes Trageholster
1321.1211P81 6.960,00 € 8.282,40 € ZPH-AA2 Paket Cable Rider ZPH Combi Analyzer T&M Kit für RF Vision Antenna alignment bundle: Inkl. serialisiertes Produkt: Cable Rider ZPH 1321.1211K12 bestehend aus Cable Rider ZPH Combi Modell, ZPH-B4 Frequenz-Upgrade 3 GHz auf 4 GHz, ZPH-K1 Spectrumanalyse Messungen Applikation, ZN-Z103 Kalibrier-Einheit, HA-Z321 Koffer für Handhelds und Zubehör, HA-Z322 Wasserabweisendes Trageholster
1321.1211P82 12.320,00 € 14.660,80 € ZPH-COM1 ZPH Cable Rider Handheld Kabel- und Antennen Analyzer (.02)
ZPH-B4 Frequenz-Upgrade, 3 GHz auf 4 GHz
ZPH-B10 GPS-Unterstützung
ZPH-K9 Power Sensor Support
ZPH-K19 Channel Power Meter
ZPH-K29 Pulse Measurements with Power Sensor1321.1211P98 7.540,00 € 8.972,60 € ZPH-COM2 ZPH Cable Rider Handheld Combi model & Spektrumanalysator (.12)
ZPH-B4 Frequency Upgrade, 3 GHz to 4 GHz
ZPH-B22 Preamplifier
ZPH-K1 Spectrum analysis measurement application
ZPH-K15 Interference Analysis
ZPH-K16 Signal Strength Mapping Measurement Application
ZPH-K7 Modulation Analysis
ZPH-K9 Power Sensor Support
ZPH-K19 Channel Power Meter
ZPH-K29 Pulse Measurements with Power Sensor
Promotion: Today´s solution for tomorrow´s challenge1321.1211P99 16.217,00 €
11.350,00 €
19.298,23 €
13.506,50 €ZPH-K105 EMF measurement application
(unregistrierte Lizenz) (Link: Application Note als pdf-Datei)1334.7207.03 1.980,00 € 2.356,20 € Software Optionen ZPH-B4 Frequenz-Upgrade, 3 GHz auf 4 GHz (Software Lizenz) 1321.0380.02 850,00 € 1.011,50 € ZPH-B4 Frequenz-Upgrade, 3 GHz auf 4 GHz (unregistrierte Lizenz) 1321.0380.03 850,00 € 1.011,50 € ZPH-B10 GPS-Unterstützung nur für Model .02 (Software Lizenz) 1321.0396.02 315,00 € 374,85 € ZPH-B10 GPS-Unterstützung nur für Model .02 (unregistrierte Lizenz) 1321.0396.03 315,00 € 374,85 € ZPH-B22 Spectrum Analyzer Preamplifier (erfordert ZPH-K1), (nur für Modell .12) (Software Lizenz) 1334.5627.02 430,00 € 511,70 € ZPH-B22 Spectrum Analyzer Preamplifier (erfordert ZPH-K1), (nur für Modell .12) (unregistrierte Lizenz) 1334.5627.03 430,00 € 511,70 € ZPH-K1 Spectrum Analysis Measurement Application (nur für Modell .12) (Software Lizenz) 1334.5604.02 2.790,00 € 3.320,10 € ZPH-K1 Spectrum Analysis Measurement Application (nur für Modell .12) (unregistrierte Lizenz) 1334.5604.03 2.790,00 € 3.320,10 € ZPH-K7 Modulation Analysis AM/FM/ASK/FSK ( erfordert ZPH-K1), (nur für Modell .12) (Software Lizenz) 1334.5633.02 620,00 € 737,80 € ZPH-K7 Modulation Analysis AM/FM/ASK/FSK ( erfordert ZPH-K1), (nur für Modell .12) (unregistrierte Lizenz) 1334.5633.03 620,00 € 737,80 € ZPH-K9 Messungen mit Leistungsmessköpfen (Software Lizenz) 1321.0415.02 535,00 € 636,65 € ZPH-K9 Messungen mit Leistungsmessköpfen (unregistrierte Lizenz) 1321.0415.03 535,00 € 636,65 € ZPH-K15 Interference Analysis (erfordert ZPH-K1), (nur für Modell .12) (Software Lizenz) 1334.5640.02 1.180,00 € 1.404,20 € ZPH-K15 Interference Analysis (erfordert ZPH-K1), (nur für Modell .12) (unregistrierte Lizenz) 1334.5640.03 1.180,00 € 1.404,20 € ZPH-K16 Signal Strength Mapping Measurement Application (erfordert ZPH-K1), (nur für Modell .12) (Software Lizenz) 1334.5656.02 1.180,00 € 1.404,20 € ZPH-K16 Signal Strength Mapping Measurement Application (erfordert ZPH-K1), (nur für Modell .12) (unregistrierte Lizenz) 1334.5656.03 1.180,00 € 1.404,20 € ZPH-K19 Kanal-Leistungsmesser (Software Lizenz) 1321.0409.02 690,00 € 821,10 € ZPH-K19 Kanal-Leistungsmesser (unregistrierte Lizenz) 1321.0409.03 690,00 € 821,10 € ZPH-K29 Pulsmessungen mit Power Sensor (Software Lizenz) 1321.0421.02 1.160,00 € 1.380,40 € ZPH-K29 Pulsmessungen mit Power Sensor (unregistrierte Lizenz) 1321.0421.03 1.160,00 € 1.380,40 € ZPH-K43 Applikation Messempfänger und Channel-Scan (ZPH-K1 erforderlich)
(unregistrierte Lizenz)1334.5662.03 Auf Anfrage ZPH-K45 Vektor-Voltmeter Messungen Applikation (Software-Lizenz) 1334.5679.02 Auf Anfrage ZPH-K57 Erweiterte Gated Trigger Messungen:
- Adjacent Channel Leakage Power Ratio (ACLR)
- Occupied Bandwidth (OBW)
- Spectrum Emission Mask (SEM)
(Software-Lizenz)1334.5685.02 600,00 € 714,00 € Infos zu Gewährleistungsverlängerung und Gerätekalibrierung
finden Sie unter "Serviceoptionen"
Wir erstellen Ihnen gerne ein detailiertes AngebotPreise Stand 2024-04-01 - Preisirrtum vorbehalten -
Es gelten die Preise aus unseren Angeboten - Zubehör allg.
-
Modell Bezeichnung R&S Bestellnr. Preis (€)
zuzügl. MwStPreis (€)
inkl. MwStMessleitungen (N-, BNC-, Interface-Kabel) FSH-Z144 USB-Adapterkabel (USB-Stecker auf Binder-Stecker) für FSH-Z14/ FSH-Z44 Durchgangs-Leistungsmessköpfe zum Anschluß an den FSH/ ZVH/ ZPH Handheld-Analysator, Länge 1,8 m 1145.5909.02 165,00 € 196,35 € TSEMF-CV Konverterkabel 1158.9250.02 Auf Anfrage FSH-Z320 HF-Kabel, Länge: 1 m, N-Stecker/N-Buchse für Option FSH-K41, bis 8 GHz 1309.6600.00 275,00 € 327,25 € FSH-Z321 HF-Kabel, Länge: 3 m, N-Stecker/N-Buchse für Option FSH-K41, bis 8 GHz 1309.6617.00 365,00 € 434,35 € HE300USB Serial an USB Adapter zum Anschluss des HE300-, HE400- oder HL300-Steuerkabels an einen USB Port. Länge ca. 30cm USB Typ A Stecker - Binder 7 pol. Subminiatur-Buchse 4080.9440.02 320,00 € 380,80 € HA-Z211 Ersatz-USB-Kabel 1309.6169.00 36,00 € 42,84 € HA-Z210 Ersatz-LAN-Kabel 1309.6152.00 27,00 € 32,13 € NRP-ZKU USB Interface Kabel für NRP-Messköpfe, L= 1.5 m (für NRPxxS/T/A/SN/TN/AN) - Messkopfbetrieb am Laptop/PC;
Stromversorgung über USB . Stecker: M12(sensorseitig) - USB A1419.0658.03 227,00 € 270,13 € NRP-ZKC USB Leistungsmesskopfkabel L=0,75m für NRPxxS/T/A/SN/TN/AN Messkopfbetrieb
Stromversorgung über USB, Stecker: M12(sensorseitig) - USB-C1425.2442.02 227,00 € 270,13 € NRP-ZKC USB Leistungsmesskopfkabel L=1,5m für NRPxxS/T/A/SN/TN/AN Messkopfbetrieb
Stromversorgung über USB, Stecker: M12(sensorseitig) - USB-C1425.2442.03 248,00 € 295,12 € NRP-ZKC USB Leistungsmesskopfkabel L=3,0m für NRPxxS/T/A/SN/TN/AN Messkopfbetrieb
Stromversorgung über USB, Stecker: M12(sensorseitig) - USB-C1425.2442.04 289,00 € 343,91 € NRP-Z4 USB-Adapter Kabel (passiv), Länge 2 m , zum Anschluss von NRP-Z211 und NRP-Z221 Leistungsmessköpfen z.B. an ZVH, SMB100B, ZPH, etc. 1146.8001.02 227,00 € 270,13 € Adapter Adapter Adapter N (m) – BNC (f) 0118.2812.00 Auf Anfrage Adapter Adapter N (m) – N (m) 0092.6581.00 Auf Anfrage Adapter Adapter N (m) – SMA (f) 4012.5837.00 Auf Anfrage Adapter Adapter N (m) – 7/16 (f) 3530.6646.00 Auf Anfrage Adapter Adapter N (m) – 7/16 (m) 3530.6630.00 Auf Anfrage Adapter Adapter N (m) – FME (f) 4048.9790.00 Auf Anfrage Adapter Adapter BNC (m) – Banana (f) 0017.6742.00 Auf Anfrage Anpassglieder RAZ Anpassglied 50/75 Ohm, 0 - 2700 MHz, zur einseitigen Anpassung, N-Anschlüsse
(Link: Details als pdf-Datei)0358.5714.02 960,00 € 1.142,40 € RAM Anpassglied 50/75 Ohm, 0 - 2700 MHz, zur beidseitigen
Anpassung, N-Anschlüsse
(Link: Details als pdf-Datei)0358.5414.02 960,00 € 1.142,40 € FSH-Z38 Anpassglied, 50 Ω/75 Ω, bidirektional, 0 Hz bis 1 GHz,
BNC-Buchse/N-Stecker, Belastbarkeit 1 W1300.7740.02 350,00 € 416,50 € Dämpfungsglieder RDL50 Leistungsdämpfungsglied, 50 W, 20 dB, 50 Ω, DC bis 6 GHz, N(f) – N(m) 1035.1700.52 1.180,00 € 1.404,20 € RBU100 Leistungsdämpfungsglied, 100 W, 3 dB, 50 Ω, DC bis 2 GHz, N(f) – N(m) 1073.8495.03 2.820,00 € 3.355,80 € RBU100 Leistungsdämpfungsglied, 100 W, 6 dB, 50 Ω, DC bis 2 GHz, N(f) – N(m) 1073.8495.06 2.820,00 € 3.355,80 € RBU100 Leistungsdämpfungsglied, 100 W, 10 dB, 50 Ω, DC bis 2 GHz, N(f) – N(m) 1073.8495.10 2.820,00 € 3.355,80 € RBU100 Leistungsdämpfungsglied, 100 W, 20 dB, 50 Ω, DC bis 2 GHz, N(f) – N(m) 1073.8495.20 2.820,00 € 3.355,80 € RBU100 Leistungsdämpfungsglied, 100 W, 30 dB, 50 Ω, DC bis 2 GHz, N(f) – N(m) 1073.8495.30 2.820,00 € 3.355,80 € Kalibriereinheit FSH-Z29 Kalibrierstandards Leerlauf/ Kurzschluss/ 50 Ohm-Abschluss kombiniert, zur Kalibrierung der VSWR- und DTF-Messung, DC bis 3,6 GHz 1300.7510.03 610,00 € 725,90 € Batterie Packs / Ladegeräte HA-Z301 Ersatznetzteil, einschließlich Netzstecker für EU, GB, US, AUS, CH (für z.B. FPH) 1321.1386.02 195,00 € 232,05 € HA-Z302 Car Adpater 1321.1340.02 140,00 € 166,60 € HA-Z303 Ladegerät für Lithium-Ionen Akku HA-Z306 1321.1328.02 375,00 € 446,25 € HA-Z306 Lithium-Ionen Akku Pack, 6,4 Ah 1321.1334.02 345,00 € 410,55 € Taschen / Koffer RTH-Z4 Hartschalen-Transportkoffer (für RTH, FPH, ZPH, ZNH) 1326.2774.02 260,00 € 309,40 € HA-Z220 Tragetasche B×H×T: 260 ×360×280 mm (für ZPH, FPH, RTH, FSH, ZNH, ZVH) 1309.6175.00 330,00 € 392,70 € HA-Z321 Transportkoffer für Handhelds mit Zubehör (für ZPH, FPH, FSH, ZNH, ZVH) (Bild) 1321.1357.02 435,00 € 517,65 € HA-Z322 (.02) Trageholster (wasserabweisend) für Handheldgeräte FPH, ZPH, ZNH 1321.1370.02 350,00 € 416,50 € HA-Z322 (.03) Regensicheres Trageholster Handheldgeräte für FPH, ZPH, ZNH 1321.1370.03 390,00 € 464,10 € FSH-Z36 Kopfhörer FSC, FSH3/6/18, FSH4/8, ZPH etc 1145.5838.02 35,70 € 42,48 € weiteres Messgerätezubehör:
Messleitungen, Adapter, etc.Coax-Kabel Testline N auf N Coax-Kabel Länge: 0,6 m
(Link: Datenblatt (pdf))auf Anfrage Coax-Kabel Testline N auf N Coax-Kabel Länge: 1 m
(Link: Datenblatt (pdf))auf Anfrage Coax-Kabel Testline N auf N Coax-Kabel Länge: 6 m
(Link: Datenblatt (pdf))auf Anfrage Coax-Kabel Testline Coax-Kabel mit verschiedenen Steckern und Längen
(Link: Datenblatt (pdf))Auf Anfrage Adapter N auf SMA 18,00 € 21,42 € Adapter BNC auf N 12,00 € 14,28 € Adapter BNC auf SMA 12,00 € 14,28 € Infos zu Gewährleistungsverlängerung und Gerätekalibrierung
finden Sie unter "Serviceoptionen"
Wir erstellen Ihnen gerne ein detailiertes AngebotPreise Stand 2024-04-01 - Preisirrtum vorbehalten -
Es gelten die Preise aus unseren Angeboten - Powersensoren
-
Modell Bezeichnung R&S Bestellnr. Preis (€)
zuzügl. MwStPreis (€)
inkl. MwStLink: Details zu Leistungsmessköpfen NRP-Z81 1 nW bis 100 mW, 50 MHz bis 18 GHz 1137.9009.02 Auf Anfrage NRP-Z85 1 nW bis 100 mW, 50 MHz bis 40 GHz, (2,92 mm) 1411.7501.02 Auf Anfrage NRP-Z86 1 nW bis 100 mW, 50 MHz bis 40 GHz, (2,40 mm) 1417.0109.40 Auf Anfrage NRP-Z86 1 nW bis 100 mW, 50 MHz bis 44 GHz (2,40 mm) 1417.0109.44 Auf Anfrage Mittelwert-Leistungs-Messköpfe NRP6A 100 pW bis 200 mW, 8 kHz bis 6 GHz 1424.6796.02 Auf Anfrage NRP18A 100 pW bis 200 mW, 8 kHz bis 18 GHz Average Leistungsmesskopf
benötigt USB Sensor-Kabel NRP-ZKU oder Messkopfkabel NRP-ZK6
Gerät ist abgekündigt, aktuellen Preis bitte anfragen1424.6815.02 5.730,00 € 6.818,70 € Zweipfad-Dioden Leistungs-Messköpfe NRP-Z211 10 MHz bis 8 GHz, 100 mW, 2 Pfade 1417.0409.02 3.120,00 € 3.712,80 € NRP-Z211 10 MHz bis 8 GHz, 1 nW bis 100mW, N(m) mit verkürztem Kabel 0,4m>/strong> für universelle Anwendungen 1417.0409.04 3.120,00 € 3.712,80 € NRP-Z221 10 MHz bis 18 GHz, 100 mW, 2 Pfade 1417.0309.02 4.050,00 € 4.819,50 € Dreipfad-Dioden Leistungs-Messköpfe NRP8S 100 pW bis 200 mW, 10 MHz bis 8 GHz 1419.0006.02 4.481,00 € 5.332,39 € NRP18S 100 pW bis 200 mW, 10 MHz bis 18 GHz 1419.0029.02 5.367,00 € 6.386,73 € NRP33S 100 pW bis 200 mW, 10 MHz bis 33 GHz 3-Pfad Dioden Leistungsmesskopf 1419.0064.02 Auf Anfrage NRP40S 100 pW bis 200 mW, 50 MHz bis 40 GHz 1419.0041.02 Auf Anfrage NRP50S 100 pW bis 200 mW, 50 MHz bis 50 GHz 1419.0087.02 Auf Anfrage Thermische Leistungs-Messköpfe NRP18T 300 nW bis 100 mW, DC bis 18 GHz 1424.6115.02 3.657,00 € 4.351,83 € NRP33T 300 nW bis 100 mW, DC bis 33 GHz 1424.6138.02 Auf Anfrage NRP40T 300 nW bis 100 mW, DC bis 40 GHz 1424.6150.02 Auf Anfrage NRP50T 300 nW bis 100 mW, DC bis 50 GHz 1424.6173.02 Auf Anfrage NRP67T 300 nW bis 100 mW, DC bis 67 GHz 1424.6196.02 Auf Anfrage NRP110T 300 nW bis 100 mW, DC bis 110 GHz 1424.6215.02 Auf Anfrage NRP18P Puls-Leistungsmesskopf 50MHz bis 18GHz; 1nW bis 100mW, N (m)
benötigt USB Sensor-Kabel NRP-ZKU oder Messkopfkabel NRP-ZK61444.1190.02 9.044,00 € 10.762,36 € NRP-Zxx /Für NRPZxxx Leistungsmessköpfe ist zusätzlich das NRP-Z4 USB-Adapter Kabel erforderlich FSH-Z14 Durchgangsleistungsmesskopf, 30 mW bis 300 mW, 25 MHz bis 1 GHz 1444.0029.02 3.626,00 € 4.314,94 € FSH-Z44 Durchgangsleistungsmesskopf, 30 mW bis 300 W, 200 MHz bis 4 GHz 1444.0035.02 3.410,00 € 4.057,90 € Optische Leistungsmessköpfe und Zubehör HA-Z360 Optischer OEM-USB-Leistungsmesser (Germanium) 1334.5162.00 425,00 € 505,75 € HA-Z361 Optischer OEM-USB-Leistungsmesser (gefiltertes InGaAs) 1334.5179.00 515,00 € 612,85 € HA-Z362 SC-Adapter für optischen Leistungsmesser 1334.5185.00 75,00 € 89,25 € HA-Z363 LC-Adapter für optischen Leistungsmesser 1334.5191.00 75,00 € 89,25 € HA-Z364 2,5 mm Universal-Adapter für optischen Leistungsmesser 1334.5204.00 57,00 € 67,83 € HA-Z365 1,25 mm Universal-Adapter für optischen Leistungsmesser 1334.5210.00 57,00 € 67,83 € HA-Z366 Patchkabel SC-LC SM, SX, Länge: 1 m 1334.5227.00 45,00 € 53,55 € HA-Z367 Patchkabel SC-SC SM, SX, Länge: 1 m 1334.5233.00 45,00 € 53,55 € Infos zu Gewährleistungsverlängerung und Gerätekalibrierung
finden Sie unter "Serviceoptionen"
Wir erstellen Ihnen gerne ein detailiertes AngebotPreise Stand 2024-04-01 - Preisirrtum vorbehalten -
Es gelten die Preise aus unseren Angeboten - Antennen
-
Modell Bezeichnung R&S Bestellnr. Preis (€)
zuzügl. MwStPreis (€)
inkl. MwStEMV Nahfeldsonden HZ540 EMV Nahfeldsondensatz 3 GHz, bestehend aus: aktiven HZ551 E-Feld-, HZ552 H-Feld-, HZ553 Hochimpedanz-Sonden, 1x SMA-N Kabel 1,2m
abgekündigt, Verfügbarkeit anfragen3594.4196.02 HZ-15 Compact Probe Set HZ15 passive E- und H- Feldsonden 30 MHz bis 3 GHz 1147.2736.02 2.400,00 € 2.856,00 € HZ-17 Sondensatz für H-Nahfeldmessungen (passive Sonden) 1339.4141.02 1.100,00 € 1.309,00 € HZ-16 Vorverstärker 100 kHz bis 3 GHz, 20 dB, Netzadapter 100 V bis 230 V für Sondensatz HZ-15 1147.2720.02 690,00 € 821,10 € Antennen und Antennenzubehör HA-Z1900 Yagi Antenna, 1710 MHz to 1990 MHz 1328.6825.02 865,00 € 1.029,35 € HA-Z900 Yagi Antenna, 824 MHz to 960 MHz 1328.6283.02 865,00 € 1.029,35 € HA-Z901 RF Cable (length: 1 m), DC to 6 GHz, N male/N male connectors 3626.2757.02 115,00 € 136,85 € HA-Z902 Tragetasche, für HA-Z900 oder HA-Z1900 Yagi-Antenne 1328.6883.02 425,00 € 505,75 € HE400PKUWB Tragbare Richtantenne - Paket
Inkl. serialisiertes Produkt+Optionen:
HE400 Tragbare Richtantenne 4104.6000K02
bestehend aus:
- HE400 Antennengriff für HE400
- HE400-K Kabelsatz
- HE400UWB UWB Antennenmodul, 30 MHz bis 6 GHz4104.6000P02 5.875,00 € 6.991,25 € HE400PKUWC Tragbare Richtantenne mit Koffer -Paket
Inkl. serialisiertes Produkt+Optionen:
HE400 Tragbare Richtantenne 4104.6000K02
bestehend aus:
- HE400 Antennengriff für HE400
- HE400-K Kabelsatz
- HE400UWB UWB Antennenmodul 30 MHz bis 6 GHz
- HE400Z1 Transportkoffer für HE4004104.6000P03 6.620,00 € 7.877,80 € HE400BCPKU Tragbare Richtantenne (Basisversion)
Inkl. serialisiertes Produkt+Optionen:
HE400BC Tragbare Richtantenne 4104.6000K04
bestehend aus:
- HE400BC Antennengriff für HE400BC
- HE400-KB Kabelsatz
- HE400UWB UWB Antennenmodul 30 MHz bis 6 GHz4104.6000P04 3.355,00 € 3.992,45 € HE800-PA Tragbare Richtantenne
18 GHz bis 44 GHz mit Vorverstärker4115.6006.02 5.520,00 € 6.568,80 € HE800Z1 Transportkoffer für HE800-PA und HE800-DC30 4115.7660.02 500,00 € 595,00 € HE400-K Kabelsatz für HE400BC (erfordert HE300USB) 4104.7770.02 Auf Anfrage HE400HF HF-Antennenmodul für HE400, 8,3 kHz bis 30 MHz 4104.8002.02 Auf Anfrage HE400VHF VHF-Antennenmodul für HE400, 20 MHz bis 200 MHz 4104.8202.02 Auf Anfrage HE400UWB UBB-Antennenmodul für HE400, 30 MHz bis 6 GHz 4104.6900.02 Auf Anfrage HE400LP Logarithmisch-periodisches Antennenmodul für HE400, 450 MHz bis 8 GHz 4104.8402.02 Auf Anfrage HE400CEL Mobilfunk-Antennenmodul für HE400, 700 MHz bis 2500 MHz 4104.7306.02 Auf Anfrage HE400SCB S/C band antenna module, 1.7 GHz to 6 GHz 4104.7606.02 Auf Anfrage HE400SHF SHF antenna module, 5 GHz to 20 GHz 4104.8602.02 Auf Anfrage HA-Z350 Logarithmisch-periodische OEM-Antenne, 700 MHz bis 4 GHz 1321.1405.02 1.070,00 € 1.273,30 € TS-EMF Tragbares EMVU-Messsystem, Transportkoffer 1158.9295.05 Auf Anfrage TSEMF-B1 Isotrope Antenne, 30 MHz bis 3 GHz für TS-EMF 1074.5719.02 Auf Anfrage TSEMF-B2 Isotrope Antenne, 700 MHz bis 6 GHz für TS-EMF 1074.5702.02 Auf Anfrage TSEMF-B3 Isotrope Antenne, 9 kHz bis 200 MHz für TS-EMF 1074.5690.02 Auf Anfrage Infos zu Gewährleistungsverlängerung und Gerätekalibrierung
finden Sie unter "Serviceoptionen"
Wir erstellen Ihnen gerne ein detailiertes AngebotPreise Stand 2024-04-01 - Preisirrtum vorbehalten -
Es gelten die Preise aus unseren Angeboten - Videos
-
Features & Operation
- Download
-
Manuale ZPH Cable Rider Handheld Kabel- und Antennenanalysator Manual
pdf 9 MBZPH
ZNDHealth Guide - For vector network analyzers gives advice to prevent electrical and mechanical damage Flyer
pdf 1 MBFact-Sheets ZPH Cable Rider Handheld Kabel- und Antennenanalysator Fact-Sheet
pdf 1 MBApplikationen ZPH GPS-Bundle
One-port cable and antenna analyzer with GPS supportpdf download FSH, FPH, ZVH, ZPH, HE400 Fast 5G NR – interference hunting in the uplink of TDD networks pdf download FPH, ZPH EMF measurement application for frequency selective measurements
Option -K105pdf download Firmware ZPH Firmware ext. Link R&S Website:
ZPH Firmware DownloadGerätetreiber ZPH folgt in Kürze Software InstrumentView
MobileViewInstrumentView (PC-Software),
MobileView (iOS/ Android-App)
Kostenlose Software für
Oszilloskope RTA4000, RTM3000, RTB2000, RTC1000, RTH,
Spektrumanalysatoren FPC, FSC, FSH, FPH, ZPH, ZVH,
Netzwerkanalysatoren ZNHSoftware Details RSCommander kostenloses Software-Tool für Spektrum-/ Netzwerkanalysatoren, Signalgeneratoren, Oszilloskope von Rohde & Schwarz. Software Details - Serviceoptionen
-
Modell Bezeichnung R&S Bestellnr. für Gerätetyp für Geräte Art.-Nr. Preis (€)
zuzügl. MwStPreis (€)
inkl. MwStPreise Stand 2023-03-01 - Preisirrtum vorbehalten -
Kalibrierpreise & weitere Service-Optionen bitte
immer anfragen. Wir erstellen Ihnen gerne ein
detailiertes Angebot
Es gelten die Preise aus unseren AngebotenWE1ZPH Extension of the 3 year standard
product warranty to 4 years
for ZPH:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair3597.0640S02 ZPH 1321.1211.02 366,00 € 435,54 € WE1ZPH Extension of the 3 year standard
product warranty to 4 years
for ZPH:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair3598.2446S02 ZPH 1321.1211.12 516,00 € 614,04 € WE2ZPH Extension of the 3 year standard
product warranty to 5 years
for ZPH:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair3597.0640S03 ZPH 1321.1211.02 697,00 € 829,43 € WE2ZPH Extension of the 3 year standard
product warranty to 5 years
for ZPH:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair3598.2446S03 ZPH 1321.1211.12 983,00 € 1.169,77 € CW1ZPH Extension of the 3 year standard
product warranty to 4 years
and Calibration Coverage
for ZPH
for 4 years:
- 3 scheduled R&S®Manufacturer-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Manufacturer-Calibrations
after repair or option upgrade3597.0640S06 ZPH 1321.1211.02 938,00 € 1.116,22 € CW1ZPH Extension of the 3 year standard
product warranty to 4 years
and Calibration Coverage
for ZPH
for 4 years:
- 3 scheduled R&S®Manufacturer-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Manufacturer-Calibrations
after repair or option upgrade3598.2446S06 ZPH 1321.1211.12 1.378,00 € 1.639,82 € CW2ZPH Extension of the 3 year standard
product warranty to 5 years
and Calibration Coverage
for ZPH
for 5 years:
- 4 scheduled R&S®Manufacturer-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Manufacturer-Calibrations
after repair or option upgrade3597.0640S07 ZPH 1321.1211.02 1.450,00 € 1.725,50 € CW2ZPH Extension of the 3 year standard
product warranty to 5 years
and Calibration Coverage
for ZPH
for 5 years:
- 4 scheduled R&S®Manufacturer-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Manufacturer-Calibrations
after repair or option upgrade3598.2446S07 ZPH 1321.1211.12 2.118,00 € 2.520,42 € AW1ZPH Extension of the 3 year standard
product warranty to 4 years
and Accredited Calibration Coverage
for ZPH
for 4 years:
- 3 scheduled R&S®Accredited-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Accredited-Calibrations
after repair or option upgrade3597.0640S14 ZPH 1321.1211.02 1.158,00 € 1.378,02 € AW1ZPH Extension of the 3 year standard
product warranty to 4 years
and Accredited Calibration Coverage
for ZPH
for 4 years:
- 3 scheduled R&S®Accredited-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Accredited-Calibrations
after repair or option upgrade3598.2446S14 ZPH 1321.1211.12 1.819,00 € 2.164,61 € AW2ZPH Extension of the 3 year standard
product warranty to 5 years
and Accredited Calibration Coverage
for ZPH
for 5 years:
- 4 scheduled R&S®Accredited-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Accredited-Calibrations
after repair or option upgrade3597.0640S15 ZPH 1321.1211.02 1.750,00 € 2.082,50 € AW2ZPH Extension of the 3 year standard
product warranty to 5 years
and Accredited Calibration Coverage
for ZPH
for 5 years:
- 4 scheduled R&S®Accredited-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Accredited-Calibrations
after repair or option upgrade3598.2446S15 ZPH 1321.1211.12 2.569,00 € 3.057,11 € ACAZPH R&S®Accredited Calibration for
ZPH:
- Akkreditiertes Kalibrierzertifikat
- Akkreditiert nach ISO 17025, ISO 9001
zertifiziert, rückführbar auf
nationale/
internationale Standards
- Verifizierung vollständiger Produkt-
spezifikation nach Verfahren wie bei
der Herstellung, inklusive Angabe von
Messunsicherheiten/Guardbanding
3597.0640.03 ZPH 394,00 € 468,86 € ACAZPH R&S®Accredited Calibration for
ZPH:
- Akkreditiertes Kalibrierzertifikat
- Akkreditiert nach IEC/ISO 17025, ISO
9001 zertifiziert, rückführbar auf
nationale/internationale Standards
- Verifizierung vollständiger
Produktspezikifationen nach
Hersteller-Verfahren; nicht binäre
Entscheidungsregel mit Angabe von
Messunsicherheiten/Guardbanding wird
angewendet (ILAC-G8)
- Kalibrierergebnisse bei Anlieferung3597.1975.03 ZPH 435,00 € 517,65 € ACAZPH R&S®Accredited Calibration for
ZPH:
- Akkreditiertes Kalibrierzertifikat
- Akkreditiert nach IEC/ISO 17025, ISO
9001 zertifiziert, rückführbar auf
nationale/internationale Standards
- Verifizierung vollständiger
Produktspezikifationen nach
Hersteller-Verfahren; nicht binäre
Entscheidungsregel mit Angabe von
Messunsicherheiten/Guardbanding wird
angewendet (ILAC-G8)
- Kalibrierergebnisse bei Anlieferung3598.2446.03 ZPH 655,00 € 779,45 €
Features & Optionen
Leistungsmessung mit Leistungsmessköpfen (Option ZPH-K9)
Manche Anwendungen erfordern eine sehr hohe Genauigkeit bei der Messung und Anpassung von Senderpegeln. Mit der Option R&S®ZPH-K9 und den R&S®NRP-Zxx Leistungsmessköpfen führt der R&S®Cable Rider ZPH Leistungsmessungen im Bereich von –67 dBm bis +45 dBm durch und deckt dabei Frequenzen bis 110 GHz ab.
Kanalleistungsmessung (Option ZPH-K19)
Die Option R&S®ZPH-K19 Kanalleistungsmessung verwandelt den Analysator in ein tragbares Leistungsmessgerät mit einer Pegelmessgenauigkeit von typischerweise 0,5 dB. Mit dieser Option erhalten Anwender schnell und unkompliziert Leistungsmessergebnisse, ohne einen Leistungsmesskopf zu benötigen.
Pulsmessung mit Leistungsmesskopf
(Option ZPH-K29)
Die Option R&S®ZPH-K29 ermöglicht genaue Puls- und Spitzenleistungsmessungen, wenn der R&S®Cable Rider ZPH zusammen mit einem Breitbandmesskopf von Rohde & Schwarz verwendet wird. Die Breitbandmessköpfe messen Pulse mit einer Auflösung von bis zu 50 ns und unterstützen Frequenzen bis zu 44 GHz. Die Option ist nützlich, wenn der R&S®Cable Rider ZPH zur Installation und Wartung von Radarsendeanlagen eingesetzt wird.
Vertrieb und Distribution
Die Allice Messtechnik GmbH mit Sitz in Frankfurt ist seit 20 Jahren Rohde & Schwarz Service- und Vertriebspartner.
Bei Allice finden Sie sowohl technischen Support als auch Service- und Kalibrier-Dienstleistungen für R&S Messgeräte.
Lassen Sie sich ein Angebot zu tagesaktuellen Konditionen erstellen – oder rufen Sie einfach einen Messtechnik-Spezialisten an.
