R&S FPL1000
Der R&S FPL1000 Spektrumanalysator bietet solide HF-Performance in einem kompakten Gehäuse. Batteriebetrieben ist er uneingeschränkt portabel und kann sowohl im Labor als auch im Feld eingesetzt werden.
Neben den Funktionen zur Spektrumanalyse unterstützt der FPL1000 auch hochgenaue Leistungsmessungen mit Leistungsmessköpfen und die Analyse von analog und digital modulierten Signalen.
- Frequenzbereich 5 kHz bis 3 GHz / 7,5 GHz / 14 GHz / 26,5 GHz
- 10,1″ Touchscreen (1280 x 800px)
- SSB phase noise: –108 dBc (1 Hz) bei 10 kHz Offset (1 GHz Träger)
- DANL mit Vorverstärker –163 dBm von 10 MHz bis 2 GHz
- Batterie oder 12/24 V DC Betrieb (Option)
- Leistungsmessung mit Leistungs-Messköpfen (Option)
- 40 MHz Bandbreite für die Analyse von analogen und digitalen Signalen (Option)
- Analog- und digital Signal-Analyse (Option)
- Phase Noise Measurement Application (Option FPL1-K40)
Alle Listenpreise finden Sie unter Geräte & Optionen sowie Zubehör
Modell | Bezeichnung | R&S Bestellnr. | Preis (€) zuzügl. MwSt | Preis (€) inkl. MwSt |
---|---|---|---|---|
FPL1003 | Signal- und Spektrumanalysator 5 kHz bis 3 GHz | 1304.0004.03 | 11.410,00 € | 13.577,90 € |
FPL1007 | Signal- und Spektrumanalysator 5 kHz bis 7,5 GHz | 1304.0004.07 | 15.010,00 € | 17.861,90 € |
FPL1007-P1 | Signal- und Spektrumanalysator 5 kHz bis 7,5 GHz inkl. FPL1-B4 OCXO reference freq. FPL1-B5 Additional Interfaces FPL1-B22 RF Preamplifier FPL1-B25 1 dB steps for electronic attenuator Promotion Today’s solution for Tomorrow’s challenge | 1304.0004P66 | 14.350,00 € | 17.076,50 € |
FPL1007-TG | Signal- und Spektrumanalysator 5 kHz bis 7,5 GHz inkl. FPL1-B4 OCXO reference freq. FPL1-B5 Additional Interfaces FPL1-B9 Internal Generator FPL1-B22 RF Preamplifier FPL1-B25 1 dB steps for electronic attenuator Promotion Today’s solution for Tomorrow’s challenge | 1304.0004P65 | 17.400,00 € | 20.706,00 € |
FPL1014 | Signal- und Spektrumanalysator 5 kHz bis 14 GHz (für max Analysebandbreite 40 MHz sind Optionen FPL1-B40 und FPL1-B11 erforderlich) | 1304.0004.14 | 26.510,00 € | 31.546,90 € |
FPL1014-P1 | Signal- und Spektrumanalysator 5 kHz bis 14 GHz inkl. FPL1-B4 OCXO reference freq. FPL1-B5 Additional Interfaces FPL1-B22 RF Preamplifier FPL1-B25 1 dB steps for electronic attenuator Promotion Today’s solution for Tomorrow’s challenge | 1304.0004P67 | 23.950,00 € | 28.500,50 € |
FPL1026 | Signal- und Spektrumanalysator 5 kHz bis 26 GHz (für max Analysebandbreite 40 MHz sind Optionen FPL1-B40 und FPL1-B11 erforderlich) | 1304.0004.26 | 30.910,00 € | 36.782,90 € |
FPL1026-P1 | Signal- und Spektrumanalysator 5 kHz bis 26,5 GHz inkl. FPL1-B4 OCXO reference freq. FPL1-B5 Additional Interfaces FPL1-B22 RF Preamplifier FPL1-B25 1 dB steps for electronic attenuator Promotion Today’s solution for Tomorrow’s challenge | 1304.0004P68 | 27.900,00 € | 33.201,00 € |
FPL-EMI3 | FPL1003 Signal- und Spektrumanalysator 5 kHz bis 3 GHz inkl. FPL1-B5 Additional Interfaces FPL1-B9 Internal Generator FPL1-B22 RF Preamplifier FPL1-K54 EMI Meas. Application Promotion Today’s solution for Tomorrow’s challenge | 1304.0004P61 | 13.700,00 € | 16.303,00 € |
FPL-EMI7 | FPL1007 Signal- und Spektrumanalysator 5 kHz bis 7,5 GHz inkl. FPL1-B5 Additional Interfaces FPL1-B9 Internal Generator FPL1-B22 RF Preamplifier FPL1-K54 EMI Meas. Application Promotion Today’s solution for Tomorrow’s challenge | 1304.0004P62 | 16.820,00 € | 20.015,80 € |
FPL1003-P1 | Paket R&S®FPL1003 Basic Package Inkl. serialisiertes Produkt FPL1003 5kHz bis 3GHz / 1304.0004K03 (entspricht FPL1003 1304.0004.03) | 1304.0010P01 | 10.870,00 € | 12.935,30 € |
FPL1003-P2 | Paket R&S®FPL1003 Advanced Package FPL1003 Spektrumanalysator 5kHz bis 3GHz / 1304.0004K03 bestehend aus: - FPL1003 5kHz bis 3GHz - FPL1-B4 OCXO Referenzfrequenz - FPL1-B5 Zusätzl. Schnittstellen - FPL1-B10 GPIB Schnittstelle | 1304.0010P02 | 13.380,00 € | 15.922,20 € |
FPL1003-P3 | Paket R&S®FPL1003 Portable Package FPL1003 Spektrumanalysator 5kHz bis 3GHz / 1304.0004K03 bestehend aus: - FPL1003 5kHz bis 3GHz - FPL1-B30 DC Netzteil für 12/24V - FPL1-B31 Interne Li-Ion Batterie | 1304.0010P03 | 13.270,00 € | 15.791,30 € |
FPL1003-P4 | Paket R&S®FPL1003 Full HW Package FPL1003 Spektrumanalysator 5kHz bis 3GHz / 1304.0004K03 bestehend aus: - FPL1003 5kHz bis 3GHz - FPL1-B4 OCXO Referenzfrequenz - FPL1-B5 Zusätzl. Schnittstellen - FPL1-B10 GPIB Schnittstelle - FPL1-B30 DC Netzteil für 12/24V - FPL1-B31 Interne Li-Ion Batterie | 1304.0010P04 | 15.780,00 € | 18.778,20 € |
FPL1003-P5 | Paket R&S®FPL1003 Tracking Generator Package FPL1003 Spektrumanalysator 5kHz bis 3GHz / 1304.0004K03 bestehend aus: - FPL1003 5 kHz bis 3 GHz - FFPL1-B4 OCXO Referenzfrequenz - FFPL1-B5 Zusätzl. Schnittstellen - FFPL1-B9 Internerl Generator - FFPL1-B10 GPIB Schnittstelle | 1304.0010P05 | 16.140,00 € | 19.206,60 € |
FPL1003-P6 | Paket R&S®FPL1003 Komplet Paket 5 kHz bis 3 GHz bestehend aus: - FPL1-B4 OCXO Freq. Reference - FPL1-B5 Additional Interfaces - FPL1-B9 Internal Generator - FPL1-B10 GPIB interface - FPL1-B22 RF Preamplifier - FPL1-B25 1 dB Step attenuator - FPL1-K7 Anal. Modulation Analysis - FPL1-K54 EMI Meas. Application | 1304.0010P06 | 21.860,00 € | 26.013,40 € |
FPL1007-P6 | Signal- und Spektrumanalysator 5 kHz bis 7,5 GHz inkl. FPL1-B4 OCXO Freq. Reference FPL1-B5 Additional Interfaces FPL1-B9 Internal Generator FPL1-B10 GPIB interface FPL1-B22 RF Preamplifier FPL1-B25 1 dB Step attenuator FPL1-K7 Anal. Modulation Analysis FPL1-K54 EMI Meas. Application | 1304.0027P06 | 26.380,00 € | 31.392,20 € |
Optionen | ||||
FPL1-B4 | OCXO-Referenzfrequenz | 1323.1902.02 | 1.170,00 € | 1.392,30 € |
FPL1-B5 | Additional Interfaces, Connector (f) 25-pin D-Sub, input/output TTL-compatible, - Noise source control and power sensor: Connectors for FS-SNSxx smart noise sources and NRP-Zxx power sensors (7-pin LEMOSA female), for noise source control switchable output voltage 0/28V (BNC (f) - IF/video/demod output: Connector BNC (f), IF out, Bandwidth equal to RBW setting, IF frequency 25 MHz - Video out: Output scaling log. / lin.; 1 V, open-circuit (nom.) - Audio output Loudspeaker built-in, adjustable, AF out: 3.5 mm mini jack, adjustable. | 1323.1883.02 | 780,00 € | 928,20 € |
FPL1-B9 | Interner Generator 5 kHz - 3 GHz (für FPL1003) (Einbau nur in Neugerät) | 1323.1925.03 | 2.890,00 € | 3.439,10 € |
FPL1-B9 | Interner Generator 5 kHz - 7.5 /14 / 26,5 GHz (für FPL1007, FPL1014, FPL1026) (Einbau nur in Neugerät) | 1323.1925.07 | 4.050,00 € | 4.819,50 € |
FPL1-B10 | GPIB-Schnittstelle (Einschubmodul) | 1323.1890.02 | 685,00 € | 815,15 € |
FPL1-B11 | YIG Preselector Bypass für Analyse Bandbreite bis 40 MHz - Überbrückung der Mikrowellenvorselektion für große Signalanalysebandbreiten bei Mittenfrequenzen > 6 GHz (Software Lizenz) | 1323.1619.02 | 2.260,00 € | 2.689,40 € |
FPL1-B19 | Zweite Festplatte | 1304.0427.02 | 765,00 € | 910,35 € |
FPL1-B22 | HF-Vorverstärker für 3 / 7,5 GHz (unregistrierte Lizenz) | 1323.1719.03 | 1.380,00 € | 1.642,20 € |
FPL1-B22 | HF-Vorverstärker, Verstärkung 20 dB für 14 GHz (unregistrierte Lizenz) | 1323.1702.03 | 2.780,00 € | 3.308,20 € |
FPL1-B22 | HF-Vorverstärker, Verstärkung 20 dB für 26,5 GHz (Software Lizenz) | 1323.1777.03 | 3.470,00 € | 4.129,30 € |
FPL1-B25 | 1-dB-Schritte für elektronische Dämpfung (unregistrierte Lizenz) | 1323.1990.03 | 810,00 € | 963,90 € |
FPL1-B30 | DC-Stromversorgung 12 V/24 V | 1323.1877.02 | 685,00 € | 815,15 € |
FPL1-B31 | Interne Lithium-Ionen-Batterie | 1323.1725.02 | 1.840,00 € | 2.189,60 € |
FPL1-B40 | 40-MHz-Analysebandbreite (unregistrierte Lizenz) (ermöglicht die Verwendung von 40 MHz Bandbreite für die Option ZNLx-B1 Spektrumanalyse) | 1323.1931.03 | 4.100,00 € | 4.879,00 € |
FPL1-K7 | AM/FM/φM Messdemodulator (unregistrierte Lizenz) | 1323.1731.03 | 2.040,00 € | 2.427,60 € |
FPL1-K9 | Leistungsmessung mit NRP Leistungsmessköpfen (unregistrierte Lizenz) z.B. für ZNL, FPL | 1323.1754.03 | 685,00 € | 815,15 € |
FPL1-K30 | Anwendung für Rauschzahlmessung (Noise figure) (unregistrierte Lizenz) | 1323.1760.03 | 5.790,00 € | 6.890,10 € |
FPL1-K40 | Phase Noise Measurement Applikation (unregistrierte Lizenz) | 1323.1831.03 | 5.330,00 € | 6.342,70 € |
FPL1-K54 | EMI-Messapplikation (unregistrierte Lizenz) | 1323.1783.03 | 1.770,00 € | 2.106,30 € |
FPL1-K70 | Vektorsignalanalyse (unregistrierte Lizenz) | 1323.1748.03 | 9.780,00 € | 11.638,20 € |
FPL1-K70M | Multi-Modulationsanalyse (unregistrierte Lizenz) | 1323.1625.03 | 3.380,00 € | 4.022,20 € |
FPL1-K70P | Bitfehlerratenmessungen mit PRBS-Daten (unregistrierte Lizenz) | 1323.1631.03 | 3.040,00 € | 3.617,60 € |
Infos zu Gewährleistungsverlängerung und Gerätekalibrierung finden Sie unter "Serviceoptionen" Wir erstellen Ihnen gerne ein detailiertes Angebot | ||||
Preise Stand 2024-04-01 - Preisirrtum vorbehalten - Es gelten die Preise aus unseren Angeboten |
Modell | Bezeichnung | R&S Bestellnr. | Preis (€) zuzügl. MwSt | Preis (€) inkl. MwSt |
---|---|---|---|---|
Software | ||||
Link: Details zu ELEKTRA EMI Mess-Software | ||||
ELEMI-EP | Elektra ELEMI-EP EMI TEST Paket enthält: - ELEMI-E EMV Emissions Messsoftware f. R&S Messempfänger u. Spektrumanalysatoren - EMCPC Lizenz-Dongle (enthält Chipkarte und Chipkartenleser) | 5601.0018P99 | 2.810,00 € | 3.343,90 € |
ELEMI-E | ELEKTRA EMV Messsoftware für Emissionen (unregistrierte Lizenz), (zusätzlich ist ein ELEKTRA Lizenz-Dongle ist erforderlich) | 5601.0030.03 | 2.450,00 € | 2.915,50 € |
EMCPC | ELEKTRA Lizenz-Dongle (enthält Chipkarte und Chipkartenleser); ELEKTRA Softwarelizenz zusätzlich erforderlich | 5601.0018.02 | 355,00 € | 422,45 € |
Software | ||||
VSE | Vector Signal Explorer Base Software | 1320.7500.02 | Auf Anfrage | |
VSE-K70 | Vektor Signal Analyse | 1320.7522.02 | Auf Anfrage | |
VSE-K106 | EUTRA/LTE NB-IoT Analysis | 1320.7900.02 | Auf Anfrage | |
EMV Nahfeldsonden | ||||
HZ540 | EMV Nahfeldsondensatz 3 GHz, bestehend aus: aktiven HZ551 E-Feld-, HZ552 H-Feld-, HZ553 Hochimpedanz-Sonden, 1x SMA-N Kabel 1,2m abgekündigt, Verfügbarkeit anfragen | 3594.4196.02 | ||
Antennen und Antennenzubehör | ||||
HE400UWB | UBB-Antennenmodul für HE400, 30 MHz bis 6 GHz | 4104.6900.02 | Auf Anfrage | |
Messleitungen (N-, BNC-, Interface-Kabel) | ||||
PCK | IEC/IEEE Bus Cable, length: 1 m | 0292.2013.10 | Auf Anfrage | |
PCK | IEC/IEEE Bus Cable, length: 2 m | 0292.2013.20 | Auf Anfrage | |
Adapter | ||||
Anpassglieder | ||||
RAZ | Anpassglied 50/75 Ohm, 0 - 2700 MHz, zur einseitigen Anpassung, N-Anschlüsse (Link: Details als pdf-Datei) | 0358.5714.02 | 960,00 € | 1.142,40 € |
RAM | Anpassglied 50/75 Ohm, 0 - 2700 MHz, zur beidseitigen Anpassung, N-Anschlüsse (Link: Details als pdf-Datei) | 0358.5414.02 | 960,00 € | 1.142,40 € |
Dämpfungsglieder | ||||
RDL50 | Leistungsdämpfungsglied, 50 W, 20 dB, 50 Ω, DC bis 6 GHz, N(f) – N(m) | 1035.1700.52 | 1.180,00 € | 1.404,20 € |
RBU50 | Attenuator 50 W, 3 dB, 2 GHz | 1073.8695.03 | 1.800,00 € | 2.142,00 € |
RBU50 | Attenuator 50 W, 6 dB, 2 GHz | 1073.8695.06 | 1.800,00 € | 2.142,00 € |
RBU50 | Attenuator 50 W, 10 dB, 2 GHz | 1073.8695.10 | 1.800,00 € | 2.142,00 € |
RBU50 | Attenuator 50 W, 20 dB, 2 GHz | 1073.8695.20 | 1.800,00 € | 2.142,00 € |
RBU50 | Attenuator 50 W, 30 dB, 2 GHz | 1073.8695.30 | 1.800,00 € | 2.142,00 € |
Batterie Packs / Ladegeräte | ||||
FSV-B34 | Ladegerät für Li-Ion Batteriepack FSV-B32 (HW-Opt.) | 1321.3950.02 | 1.830,00 € | 2.177,70 € |
FPL1-Z4 | Ersatz Batterie Pack für ZNL, FPL, EPL | 1323.1677.02 | 835,00 € | 993,65 € |
Tastkopf Zubehör | ||||
RT-ZA9 | N-Stecker-Adapter für RT-ZSxx Breitband-, RT-ZD10/20/30/40 Differenz-, RT-ZMxx Modular-Tastköpfe zum Anschluß an Spektrum-/ Netzwerkanalysatoren mit N-Buchsen; USB-Stecker für Stromversorgung und Kommunikation | 1417.0909.02 | 1.160,00 € | 1.380,40 € |
Taschen / Koffer | ||||
FPL1-Z1 | Transportschutzhaube für z.B. FPL1000, ZNL, ZNLE | 1323.1960.02 | 160,00 € | 190,40 € |
FPL1-Z2 | Transporttasche mit transparentem Deckel für z.B. FPL1000, ZNL, ZNLE | 1323.1977.02 | 445,00 € | 529,55 € |
FPL1-Z3 | Brusttragegurt für FPL1000 und ZNL, ZNLE (benötigt FPL1-Z2) | 1323.1683.02 | 110,00 € | 130,90 € |
FPL1-Z6 | 19" Rackmount Kit (für z.B. FPL, ZNL) | 1323.1954.02 | 220,00 € | 261,80 € |
Diverses | ||||
FSE-Z4 | DC Block, 10 kHz to 18 GHz (type N) | 1084.7443.02 | auf Anfrage | |
FPL1-Z5 | Antireflexfolie für FPL1000 und ZNL, ZNLE, EPL | 1323.1690.02 | 73,00 € | 86,87 € |
weiteres Messgerätezubehör: Messleitungen, Adapter, etc. | ||||
FPL-DP | Anti-glare Display Schutzfolie, matt - weniger Reflexionen und Fingerabdrücke - passend für FPL1000 Spektrumanalysatoren | 32,00 € | 38,08 € | |
EMInspector EMI-H | aktive H-Feldsonde 1 MHz bis 3 GHz (Nahfeldsonde empfindlich für Magnetfelder) Link: Details EMInspector | 615,00 € | 731,85 € | |
EMInspector EMI-H/E | aktive H/E-Feldsonde 1 MHz bis 3 GHz (Nahfeldsonde empfindlich für magnetische- und elektrische Felder) Link: Details EMInspector | 855,00 € | 1.017,45 € | |
Coax-Kabel | Testline N auf N Coax-Kabel Länge: 0,6 m (Link: Datenblatt (pdf)) | auf Anfrage | ||
Coax-Kabel | Testline N auf N Coax-Kabel Länge: 1 m (Link: Datenblatt (pdf)) | auf Anfrage | ||
Coax-Kabel | Testline N auf N Coax-Kabel Länge: 6 m (Link: Datenblatt (pdf)) | auf Anfrage | ||
Coax-Kabel | Testline Coax-Kabel mit verschiedenen Steckern und Längen (Link: Datenblatt (pdf)) | Auf Anfrage | ||
HZ34 | BNC Kabel Länge: 1m | 18,00 € | 21,42 € | |
Adapter | N auf SMA | 18,00 € | 21,42 € | |
Adapter | BNC auf N | 12,00 € | 14,28 € | |
Adapter | BNC auf SMA | 12,00 € | 14,28 € | |
Infos zu Gewährleistungsverlängerung und Gerätekalibrierung finden Sie unter "Serviceoptionen" Wir erstellen Ihnen gerne ein detailiertes Angebot | ||||
Preise Stand 2024-04-01 - Preisirrtum vorbehalten - Es gelten die Preise aus unseren Angeboten |
Manuale | ||||
FPL1000 | Spektrumanalysator Getting Started Manual | Manual pdf 3 MB |
||
FPL1000 | Spektrumanalysator kpl. Manual | Manual pdf 16 MB |
||
FPL1-K40 Option | FPL1-K40 Phase noise measurement | Manual pdf 9 MB |
||
Fact-Sheets | ||||
FPL1000 | Spektrumanalysator | Fact-Sheet pdf 1 MB |
||
FPL1000 | Option FPL1-B9 interner Generator | Fact-Sheet pdf 1 MB |
||
FPL1000 | Option FPL1-K7 Analog Modulation Analyse | Fact-Sheet pdf 1 MB |
||
FPL1000 | Option FPL1-K30 noise figure and gain measurements | Fact-Sheet pdf 1 MB |
||
FPL1000 | Option FPL1-K40 Phase noise measurement | Fact-Sheet pdf 1 MB |
||
FPL1000 | Option FPL1-K40 Phase noise measurement (Spezifikationen) | Spezifikationen pdf 1 MB |
||
FPL1000 | Option FPL1-K54 EMI Measurement Application | Fact-Sheet pdf 1 MB |
||
FPL1000 | Option FPL1-K70 Vector Signal Analyse | Fact-Sheet pdf 1 MB |
||
Applikationen | ||||
FPL1000 | EMI Measurement Application for Signal and Spectrum Analyzers (Option FPL-K54) | pdf download | ||
FPL, ZNL | Noise figure measurement applikation | pdf download | ||
Firmware | ||||
FPL1000 | Firmware | ext. Link R&S Website: FPL Firmware Download |
||
Gerätetreiber | ||||
FPL1000 | Gerätetreiber und Anwendungsbeispiele: z.B. für LabView, IVI.Net, LabWindows/CVI, VXI, VBA, C#, C++, etc. | ext. Link R&S Website: FPL1000 Gerätetreiber Download |
||
Software | ||||
ELEKTRA EMV Mess Software | Software für EMV-Messempfänger: ESCI, ESPI, ESL, ESR, ESU, ESRP, ESW etc. - Spektrumanalysatoren: FSL, FPC, Spectrum Rider FPH, FSV, FSW, FPL etc. - Netznachbildungen: HM6050, ENV216 | Software Details | ||
RSCommander | kostenloses Software-Tool für Spektrum-/ Netzwerkanalysatoren, Signalgeneratoren, Oszilloskope von Rohde & Schwarz. | Software Details | ||
FPL1000/ SMBV | R&S ARB Toolbox - Mit der Software lassen sich ARB-Wellenform-Dateien aus benutzerdefinierten I/Q-Daten erstellen, Daten aus .mat-Dateien aus MATLAB importieren, Wellenforminhalte grafisch auswerten, Wellenformen neu sampeln oder filtern, analoge modulierte Signale als ARB-Dateien erstellen, Marker-Daten in Wellenformdateien bearbeiten oder per Composer komplexe Szenarien mit mehreren Trägern generieren. | ext. Link R&S Website: ARB ToolboxDownload |
Modell | Bezeichnung | R&S Bestellnr. | für Gerätetyp | für Geräte Art.-Nr. | Preis (€) zuzügl. MwSt | Preis (€) inkl. MwSt |
---|---|---|---|---|---|---|
Preise Stand 2023-03-01 - Preisirrtum vorbehalten - Kalibrierpreise & weitere Service-Optionen bitte immer anfragen. Wir erstellen Ihnen gerne ein detailiertes Angebot Es gelten die Preise aus unseren Angeboten | ||||||
WE1FPL1003 | Extension of the 3 year standard product warranty to 4 years for FPL1003: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair Extension of the 3 year standard product warranty to 4 years for FPL1003: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair | 3597.9930S02 | FPL1003 | 1304.0004.03 | 424,00 € | 504,56 € |
WE2FPL1003 | Extension of the 3 year standard product warranty to 5 years for FPL1003: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair Extension of the 3 year standard product warranty to 5 years for FPL1003: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair | 3597.9930S03 | FPL1003 | 1304.0004.03 | 808,00 € | 961,52 € |
WE1FPL1007 | Extension of the 3 year standard product warranty to 4 years for FPL1007: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair Extension of the 3 year standard product warranty to 4 years for FPL1007: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair | 3597.9982S02 | FPL1007 | 1304.0004.07 | 460,00 € | 547,40 € |
WE2FPL1007 | Extension of the 3 year standard product warranty to 5 years for FPL1007: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair Extension of the 3 year standard product warranty to 5 years for FPL1007: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair | 3597.9982S03 | FPL1007 | 1304.0004.07 | 876,00 € | 1.042,44 € |
WE1FPL1014 | Extension of the 3 year standard product warranty to 4 years for FPL1014: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair Extension of the 3 year standard product warranty to 4 years for FPL1014: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair | 3598.8950S02 | FPL1014 | 1304.0004K14 | 471,00 € | 560,49 € |
WE2FPL1014 | Extension of the 3 year standard product warranty to 5 years for FPL1014: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair Extension of the 3 year standard product warranty to 5 years for FPL1014: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair | 3598.8950S03 | FPL1014 | 1304.0004K14 | 896,00 € | 1.066,24 € |
WE1FPL1026 | Extension of the 3 year standard product warranty to 4 years for FPL1026: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair Extension of the 3 year standard product warranty to 4 years for FPL1026: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair | 3598.8944S02 | FPL1026 | 1304.0004K26 | 493,00 € | 586,67 € |
WE2FPL1026 | Extension of the 3 year standard product warranty to 5 years for FPL1026: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair Extension of the 3 year standard product warranty to 5 years for FPL1026: - All repairs and all necessary R&S®Manufacturer-Calibrations in case of repair | 3598.8944S03 | FPL1026 | 1304.0004K26 | 939,00 € | 1.117,41 € |
CW1FPL1003 | Extension of the 3 year standard product warranty to 4 years and Calibration Coverage for FPL1003 for 4 years: - 3 scheduled R&S®Manufacturer- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Manufacturer-Calibrations after repair or option upgrade | 3597.9930S06 | FPL1003 | 1304.0004.03 | 1.729,00 € | 2.057,51 € |
CW2FPL1003 | Extension of the 3 year standard product warranty to 5 years and Calibration Coverage for FPL1003 for 5 years: - 4 scheduled R&S®Manufacturer- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Manufacturer-Calibrations after repair or option upgrade | 3597.9930S07 | FPL1003 | 1304.0004.03 | 2.526,00 € | 3.005,94 € |
CW1FPL1007 | Extension of the 3 year standard product warranty to 4 years and Calibration Coverage for FPL1007 for 4 years: - 3 scheduled R&S®Manufacturer- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Manufacturer-Calibrations after repair or option upgrade | 3597.9982S06 | FPL1007 | 1304.0004.07 | 1.866,00 € | 2.220,54 € |
CW2FPL1007 | Extension of the 3 year standard product warranty to 5 years and Calibration Coverage for FPL1007 for 5 years: - 4 scheduled R&S®Manufacturer- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Manufacturer-Calibrations after repair or option upgrade | 3597.9982S07 | FPL1007 | 1304.0004.07 | 2.727,00 € | 3.245,13 € |
CW1FPL1014 | Extension of the 3 year standard product warranty to 4 years and Calibration Coverage for FPL1014 for 4 years: - 3 scheduled R&S®Manufacturer- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Manufacturer-Calibrations after repair or option upgrade | 3598.8950S06 | FPL1014 | 1304.0004K14 | 2.030,00 € | 2.415,70 € |
CW2FPL1014 | Extension of the 3 year standard product warranty to 5 years and Calibration Coverage for FPL1014 for 5 years: - 4 scheduled R&S®Manufacturer- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Manufacturer-Calibrations after repair or option upgrade | 3598.8950S07 | FPL1014 | 1304.0004K14 | 2.948,00 € | 3.508,12 € |
CW1FPL1026 | Extension of the 3 year standard product warranty to 4 years and Calibration Coverage for FPL1026 for 4 years: - 3 scheduled R&S®Manufacturer- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Manufacturer-Calibrations after repair or option upgrade | 3598.8944S06 | FPL1026 | 1304.0004K26 | 2.256,00 € | 2.684,64 € |
CW2FPL1026 | Extension of the 3 year standard product warranty to 5 years and Calibration Coverage for FPL1026 for 5 years: - 4 scheduled R&S®Manufacturer- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Manufacturer-Calibrations after repair or option upgrade | 3598.8944S07 | FPL1026 | 1304.0004K26 | 3.260,00 € | 3.879,40 € |
AW1FPL1003 | Extension of the 3 year standard product warranty to 4 years and Accredited Calibration Coverage for FPL1003 for 4 years: - 3 scheduled R&S®Accredited- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Accredited-Calibrations after repair or option upgrade | 3597.9930S14 | FPL1003 | 1304.0004.03 | 2.625,00 € | 3.123,75 € |
AW2FPL1003 | Extension of the 3 year standard product warranty to 5 years and Accredited Calibration Coverage for FPL1003 for 5 years: - 4 scheduled R&S®Accredited- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Accredited-Calibrations after repair or option upgrade | 3597.9930S15 | FPL1003 | 1304.0004.03 | 3.480,00 € | 4.141,20 € |
AW1FPL1007 | Extension of the 3 year standard product warranty to 4 years and Accredited Calibration Coverage for FPL1007 for 4 years: - 3 scheduled R&S®Accredited- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Accredited-Calibrations after repair or option upgrade | 3597.9982S14 | FPL1007 | 1304.0004.07 | 2.830,00 € | 3.367,70 € |
AW2FPL1007 | Extension of the 3 year standard product warranty to 5 years and Accredited Calibration Coverage for FPL1007 for 5 years: - 4 scheduled R&S®Accredited- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Accredited-Calibrations after repair or option upgrade | 3597.9982S15 | FPL1007 | 1304.0004.07 | 3.750,00 € | 4.462,50 € |
AW1FPL1014 | Extension of the 3 year standard product warranty to 4 years and Accredited Calibration Coverage for FPL1014 for 4 years: - 3 scheduled R&S®Accredited- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Accredited-Calibrations after repair or option upgrade | 3598.8950S14 | FPL1014 | 1304.0004K14 | 3.136,00 € | 3.731,84 € |
AW2FPL1014 | Extension of the 3 year standard product warranty to 5 years and Accredited Calibration Coverage for FPL1014 for 5 years: - 4 scheduled R&S®Accredited- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Accredited-Calibrations after repair or option upgrade | 3598.8950S15 | FPL1014 | 1304.0004K14 | 4.157,00 € | 4.946,83 € |
AW1FPL1026 | Extension of the 3 year standard product warranty to 4 years and Accredited Calibration Coverage for FPL1026 for 4 years: - 3 scheduled R&S®Accredited- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Accredited-Calibrations after repair or option upgrade | 3598.8944S14 | FPL1026 | 1304.0004K26 | 3.548,00 € | 4.222,12 € |
AW2FPL1026 | Extension of the 3 year standard product warranty to 5 years and Accredited Calibration Coverage for FPL1026 for 5 years: - 4 scheduled R&S®Accredited- Calibrations according to the 12 month recommended calibration interval - All repairs and all necessary R&S®Accredited-Calibrations after repair or option upgrade | 3598.8944S15 | FPL1026 | 1304.0004K26 | 4.702,00 € | 5.595,38 € |
ACAFPL1003 | R&S®Accredited Calibration for FPL1003: - Akkreditiertes Kalibrierzertifikat - Akkreditiert nach ISO 17025, ISO 9001 zertifiziert, rückführbar auf nationale/ internationale Standards - Verifizierung vollständiger Produkt- spezifikation nach Verfahren wie bei der Herstellung, inklusive Angabe von Messunsicherheiten/Guardbanding | 3597.9930.03 | FPL1003 | 991,00 € | 1.179,29 € | |
ACAFPL1007 | R&S®Accredited Calibration for FPL1007: - Akkreditiertes Kalibrierzertifikat - Akkreditiert nach ISO 17025, ISO 9001 zertifiziert, rückführbar auf nationale/ internationale Standards - Verifizierung vollständiger Produkt- spezifikation nach Verfahren wie bei der Herstellung, inklusive Angabe von Messunsicherheiten/Guardbanding | 3597.9982.03 | FPL1007 | 1.068,00 € | 1.270,92 € | |
ACAFPL1014 | R&S®Accredited Calibration for FPL1014: - Akkreditiertes Kalibrierzertifikat - Akkreditiert nach ISO 17025, ISO 9001 zertifiziert, rückführbar auf nationale/internationale Standards - Verifizierung vollständiger Produktspezifikationen nach Verfahren wie bei der Herstellung, inklusive Angabe von Messunsicherheiten/Guardbanding | 3598.8950.03 | FPL1014 | 1.184,00 € | 1.408,96 € | |
ACAFPL1026 | R&S®Accredited Calibration for FPL1026: - Akkreditiertes Kalibrierzertifikat - Akkreditiert nach ISO 17025, ISO 9001 zertifiziert, rückführbar auf nationale/internationale Standards - Verifizierung vollständiger Produktspezifikationen nach Verfahren wie bei der Herstellung, inklusive Angabe von Messunsicherheiten/Guardbanding | 3598.8944.03 | FPL1026 | 1.339,00 € | 1.593,41 € |
-
Alle Listenpreise finden Sie unter Geräte & Optionen sowie Zubehör
- Geräte & Optionen
-
Modell Bezeichnung R&S Bestellnr. Preis (€)
zuzügl. MwStPreis (€)
inkl. MwStFPL1003 Signal- und Spektrumanalysator 5 kHz bis 3 GHz 1304.0004.03 11.410,00 € 13.577,90 € FPL1007 Signal- und Spektrumanalysator 5 kHz bis 7,5 GHz 1304.0004.07 15.010,00 € 17.861,90 € FPL1007-P1 Signal- und Spektrumanalysator 5 kHz bis 7,5 GHz
inkl.
FPL1-B4 OCXO reference freq.
FPL1-B5 Additional Interfaces
FPL1-B22 RF Preamplifier
FPL1-B25 1 dB steps for electronic attenuator
Promotion Today’s solution for Tomorrow’s challenge1304.0004P66 19.150,00 €
14.350,00 €
22.788,50 €
17.076,50 €FPL1007-TG Signal- und Spektrumanalysator 5 kHz bis 7,5 GHz
inkl.
FPL1-B4 OCXO reference freq.
FPL1-B5 Additional Interfaces
FPL1-B9 Internal Generator
FPL1-B22 RF Preamplifier
FPL1-B25 1 dB steps for electronic attenuator
Promotion Today’s solution for Tomorrow’s challenge1304.0004P65 23.200,00 €
17.400,00 €
27.608,00 €
20.706,00 €FPL1014 Signal- und Spektrumanalysator 5 kHz bis 14 GHz
(für max Analysebandbreite 40 MHz sind Optionen FPL1-B40 und FPL1-B11 erforderlich)1304.0004.14 26.510,00 € 31.546,90 € FPL1014-P1 Signal- und Spektrumanalysator 5 kHz bis 14 GHz
inkl.
FPL1-B4 OCXO reference freq.
FPL1-B5 Additional Interfaces
FPL1-B22 RF Preamplifier
FPL1-B25 1 dB steps for electronic attenuator
Promotion Today’s solution for Tomorrow’s challenge1304.0004P67 32.050,00 €
23.950,00 €
38.139,50 €
28.500,50 €FPL1026 Signal- und Spektrumanalysator 5 kHz bis 26 GHz
(für max Analysebandbreite 40 MHz sind Optionen FPL1-B40 und FPL1-B11 erforderlich)1304.0004.26 30.910,00 € 36.782,90 € FPL1026-P1 Signal- und Spektrumanalysator 5 kHz bis 26,5 GHz
inkl.
FPL1-B4 OCXO reference freq.
FPL1-B5 Additional Interfaces
FPL1-B22 RF Preamplifier
FPL1-B25 1 dB steps for electronic attenuator
Promotion Today’s solution for Tomorrow’s challenge1304.0004P68 37.140,00 €
27.900,00 €
44.196,60 €
33.201,00 €FPL-EMI3 FPL1003 Signal- und Spektrumanalysator 5 kHz bis 3 GHz inkl.
FPL1-B5 Additional Interfaces
FPL1-B9 Internal Generator
FPL1-B22 RF Preamplifier
FPL1-K54 EMI Meas. Application
Promotion Today’s solution for Tomorrow’s challenge1304.0004P61 18.280,00 €
13.700,00 €
21.753,20 €
16.303,00 €FPL-EMI7 FPL1007 Signal- und Spektrumanalysator 5 kHz bis 7,5 GHz inkl.
FPL1-B5 Additional Interfaces
FPL1-B9 Internal Generator
FPL1-B22 RF Preamplifier
FPL1-K54 EMI Meas. Application
Promotion Today’s solution for Tomorrow’s challenge1304.0004P62 23.040,00 €
16.820,00 €
27.417,60 €
20.015,80 €FPL1003-P1 Paket R&S®FPL1003 Basic Package
Inkl. serialisiertes Produkt FPL1003
5kHz bis 3GHz / 1304.0004K03
(entspricht FPL1003 1304.0004.03)1304.0010P01 10.870,00 € 12.935,30 € FPL1003-P2 Paket R&S®FPL1003 Advanced Package
FPL1003 Spektrumanalysator
5kHz bis 3GHz / 1304.0004K03
bestehend aus:
- FPL1003 5kHz bis 3GHz
- FPL1-B4 OCXO Referenzfrequenz
- FPL1-B5 Zusätzl. Schnittstellen
- FPL1-B10 GPIB Schnittstelle1304.0010P02 13.380,00 € 15.922,20 € FPL1003-P3 Paket R&S®FPL1003 Portable Package
FPL1003 Spektrumanalysator
5kHz bis 3GHz / 1304.0004K03
bestehend aus:
- FPL1003 5kHz bis 3GHz
- FPL1-B30 DC Netzteil für 12/24V
- FPL1-B31 Interne Li-Ion Batterie1304.0010P03 13.270,00 € 15.791,30 € FPL1003-P4 Paket R&S®FPL1003 Full HW Package
FPL1003 Spektrumanalysator
5kHz bis 3GHz / 1304.0004K03
bestehend aus:
- FPL1003 5kHz bis 3GHz
- FPL1-B4 OCXO Referenzfrequenz
- FPL1-B5 Zusätzl. Schnittstellen
- FPL1-B10 GPIB Schnittstelle
- FPL1-B30 DC Netzteil für 12/24V
- FPL1-B31 Interne Li-Ion Batterie1304.0010P04 15.780,00 € 18.778,20 € FPL1003-P5 Paket R&S®FPL1003 Tracking Generator Package
FPL1003 Spektrumanalysator
5kHz bis 3GHz / 1304.0004K03
bestehend aus:
- FPL1003 5 kHz bis 3 GHz
- FFPL1-B4 OCXO Referenzfrequenz
- FFPL1-B5 Zusätzl. Schnittstellen
- FFPL1-B9 Internerl Generator
- FFPL1-B10 GPIB Schnittstelle1304.0010P05 16.140,00 € 19.206,60 € FPL1003-P6 Paket R&S®FPL1003 Komplet Paket 5 kHz bis 3 GHz
bestehend aus:
- FPL1-B4 OCXO Freq. Reference
- FPL1-B5 Additional Interfaces
- FPL1-B9 Internal Generator
- FPL1-B10 GPIB interface
- FPL1-B22 RF Preamplifier
- FPL1-B25 1 dB Step attenuator
- FPL1-K7 Anal. Modulation Analysis
- FPL1-K54 EMI Meas. Application
1304.0010P06 21.860,00 € 26.013,40 € FPL1007-P6 Signal- und Spektrumanalysator 5 kHz bis 7,5 GHz inkl.
FPL1-B4 OCXO Freq. Reference
FPL1-B5 Additional Interfaces
FPL1-B9 Internal Generator
FPL1-B10 GPIB interface
FPL1-B22 RF Preamplifier
FPL1-B25 1 dB Step attenuator
FPL1-K7 Anal. Modulation Analysis
FPL1-K54 EMI Meas. Application1304.0027P06 26.380,00 € 31.392,20 € Optionen FPL1-B4 OCXO-Referenzfrequenz 1323.1902.02 1.170,00 € 1.392,30 € FPL1-B5 Additional Interfaces, Connector (f) 25-pin D-Sub, input/output TTL-compatible,
- Noise source control and power sensor: Connectors for FS-SNSxx smart noise sources and NRP-Zxx power sensors (7-pin LEMOSA female), for noise source control switchable output voltage 0/28V (BNC (f)
- IF/video/demod output: Connector BNC (f), IF out, Bandwidth equal to RBW setting, IF frequency 25 MHz
- Video out: Output scaling log. / lin.; 1 V, open-circuit (nom.)
- Audio output Loudspeaker built-in, adjustable, AF out: 3.5 mm mini jack, adjustable.1323.1883.02 780,00 € 928,20 € FPL1-B9 Interner Generator 5 kHz - 3 GHz (für FPL1003) (Einbau nur in Neugerät) 1323.1925.03 2.890,00 € 3.439,10 € FPL1-B9 Interner Generator 5 kHz - 7.5 /14 / 26,5 GHz (für FPL1007, FPL1014, FPL1026) (Einbau nur in Neugerät) 1323.1925.07 4.050,00 € 4.819,50 € FPL1-B10 GPIB-Schnittstelle (Einschubmodul) 1323.1890.02 685,00 € 815,15 € FPL1-B11 YIG Preselector Bypass für Analyse Bandbreite bis 40 MHz - Überbrückung der Mikrowellenvorselektion für große Signalanalysebandbreiten bei Mittenfrequenzen > 6 GHz (Software Lizenz) 1323.1619.02 2.260,00 € 2.689,40 € FPL1-B19 Zweite Festplatte 1304.0427.02 765,00 € 910,35 € FPL1-B22 HF-Vorverstärker für 3 / 7,5 GHz (unregistrierte Lizenz) 1323.1719.03 1.380,00 € 1.642,20 € FPL1-B22 HF-Vorverstärker, Verstärkung 20 dB für 14 GHz (unregistrierte Lizenz) 1323.1702.03 2.780,00 € 3.308,20 € FPL1-B22 HF-Vorverstärker, Verstärkung 20 dB für 26,5 GHz (Software Lizenz) 1323.1777.03 3.470,00 € 4.129,30 € FPL1-B25 1-dB-Schritte für elektronische Dämpfung (unregistrierte Lizenz) 1323.1990.03 810,00 € 963,90 € FPL1-B30 DC-Stromversorgung 12 V/24 V 1323.1877.02 685,00 € 815,15 € FPL1-B31 Interne Lithium-Ionen-Batterie 1323.1725.02 1.840,00 € 2.189,60 € FPL1-B40 40-MHz-Analysebandbreite (unregistrierte Lizenz)
(ermöglicht die Verwendung von 40 MHz Bandbreite für die Option ZNLx-B1 Spektrumanalyse)1323.1931.03 4.100,00 € 4.879,00 € FPL1-K7 AM/FM/φM Messdemodulator (unregistrierte Lizenz) 1323.1731.03 2.040,00 € 2.427,60 € FPL1-K9 Leistungsmessung mit NRP Leistungsmessköpfen (unregistrierte Lizenz) z.B. für ZNL, FPL 1323.1754.03 685,00 € 815,15 € FPL1-K30 Anwendung für Rauschzahlmessung (Noise figure) (unregistrierte Lizenz) 1323.1760.03 5.790,00 € 6.890,10 € FPL1-K40 Phase Noise Measurement Applikation (unregistrierte Lizenz) 1323.1831.03 5.330,00 € 6.342,70 € FPL1-K54 EMI-Messapplikation (unregistrierte Lizenz) 1323.1783.03 1.770,00 € 2.106,30 € FPL1-K70 Vektorsignalanalyse (unregistrierte Lizenz) 1323.1748.03 9.780,00 € 11.638,20 € FPL1-K70M Multi-Modulationsanalyse (unregistrierte Lizenz) 1323.1625.03 3.380,00 € 4.022,20 € FPL1-K70P Bitfehlerratenmessungen mit PRBS-Daten (unregistrierte Lizenz) 1323.1631.03 3.040,00 € 3.617,60 € Infos zu Gewährleistungsverlängerung und Gerätekalibrierung
finden Sie unter "Serviceoptionen"
Wir erstellen Ihnen gerne ein detailiertes AngebotPreise Stand 2024-04-01 - Preisirrtum vorbehalten -
Es gelten die Preise aus unseren Angeboten - Zubehör
-
Modell Bezeichnung R&S Bestellnr. Preis (€)
zuzügl. MwStPreis (€)
inkl. MwStSoftware Link: Details zu ELEKTRA EMI Mess-Software ELEMI-EP Elektra ELEMI-EP EMI TEST Paket enthält:
- ELEMI-E EMV Emissions Messsoftware f. R&S Messempfänger u. Spektrumanalysatoren
- EMCPC Lizenz-Dongle (enthält Chipkarte und Chipkartenleser)5601.0018P99 2.810,00 € 3.343,90 € ELEMI-E ELEKTRA EMV Messsoftware für Emissionen (unregistrierte Lizenz), (zusätzlich ist ein ELEKTRA Lizenz-Dongle ist erforderlich) 5601.0030.03 2.450,00 € 2.915,50 € EMCPC ELEKTRA Lizenz-Dongle
(enthält Chipkarte und Chipkartenleser);
ELEKTRA Softwarelizenz zusätzlich erforderlich5601.0018.02 355,00 € 422,45 € Software VSE Vector Signal Explorer Base Software 1320.7500.02 Auf Anfrage VSE-K70 Vektor Signal Analyse 1320.7522.02 Auf Anfrage VSE-K106 EUTRA/LTE NB-IoT Analysis 1320.7900.02 Auf Anfrage EMV Nahfeldsonden HZ540 EMV Nahfeldsondensatz 3 GHz, bestehend aus: aktiven HZ551 E-Feld-, HZ552 H-Feld-, HZ553 Hochimpedanz-Sonden, 1x SMA-N Kabel 1,2m
abgekündigt, Verfügbarkeit anfragen3594.4196.02 Antennen und Antennenzubehör HE400UWB UBB-Antennenmodul für HE400, 30 MHz bis 6 GHz 4104.6900.02 Auf Anfrage Messleitungen (N-, BNC-, Interface-Kabel) PCK IEC/IEEE Bus Cable, length: 1 m 0292.2013.10 Auf Anfrage PCK IEC/IEEE Bus Cable, length: 2 m 0292.2013.20 Auf Anfrage Adapter Anpassglieder RAZ Anpassglied 50/75 Ohm, 0 - 2700 MHz, zur einseitigen Anpassung, N-Anschlüsse
(Link: Details als pdf-Datei)0358.5714.02 960,00 € 1.142,40 € RAM Anpassglied 50/75 Ohm, 0 - 2700 MHz, zur beidseitigen
Anpassung, N-Anschlüsse
(Link: Details als pdf-Datei)0358.5414.02 960,00 € 1.142,40 € Dämpfungsglieder RDL50 Leistungsdämpfungsglied, 50 W, 20 dB, 50 Ω, DC bis 6 GHz, N(f) – N(m) 1035.1700.52 1.180,00 € 1.404,20 € RBU50 Attenuator 50 W, 3 dB, 2 GHz 1073.8695.03 1.800,00 € 2.142,00 € RBU50 Attenuator 50 W, 6 dB, 2 GHz 1073.8695.06 1.800,00 € 2.142,00 € RBU50 Attenuator 50 W, 10 dB, 2 GHz 1073.8695.10 1.800,00 € 2.142,00 € RBU50 Attenuator 50 W, 20 dB, 2 GHz 1073.8695.20 1.800,00 € 2.142,00 € RBU50 Attenuator 50 W, 30 dB, 2 GHz 1073.8695.30 1.800,00 € 2.142,00 € Batterie Packs / Ladegeräte FSV-B34 Ladegerät für Li-Ion Batteriepack FSV-B32 (HW-Opt.) 1321.3950.02 1.830,00 € 2.177,70 € FPL1-Z4 Ersatz Batterie Pack für ZNL, FPL, EPL 1323.1677.02 835,00 € 993,65 € Tastkopf Zubehör RT-ZA9 N-Stecker-Adapter für RT-ZSxx Breitband-, RT-ZD10/20/30/40 Differenz-, RT-ZMxx Modular-Tastköpfe zum Anschluß an Spektrum-/ Netzwerkanalysatoren mit N-Buchsen; USB-Stecker für Stromversorgung und Kommunikation 1417.0909.02 1.160,00 € 1.380,40 € Taschen / Koffer FPL1-Z1 Transportschutzhaube für z.B. FPL1000, ZNL, ZNLE 1323.1960.02 160,00 € 190,40 € FPL1-Z2 Transporttasche mit transparentem Deckel für z.B. FPL1000, ZNL, ZNLE 1323.1977.02 445,00 € 529,55 € FPL1-Z3 Brusttragegurt für FPL1000 und ZNL, ZNLE
(benötigt FPL1-Z2)1323.1683.02 110,00 € 130,90 € FPL1-Z6 19" Rackmount Kit (für z.B. FPL, ZNL) 1323.1954.02 220,00 € 261,80 € Diverses FSE-Z4 DC Block, 10 kHz to 18 GHz (type N) 1084.7443.02 auf Anfrage FPL1-Z5 Antireflexfolie für FPL1000 und ZNL, ZNLE, EPL 1323.1690.02 73,00 € 86,87 € weiteres Messgerätezubehör:
Messleitungen, Adapter, etc.FPL-DP Anti-glare Display Schutzfolie, matt - weniger Reflexionen und Fingerabdrücke - passend für FPL1000 Spektrumanalysatoren 32,00 € 38,08 € EMInspector EMI-H aktive H-Feldsonde 1 MHz bis 3 GHz
(Nahfeldsonde empfindlich für Magnetfelder)
Link: Details EMInspector615,00 € 731,85 € EMInspector EMI-H/E aktive H/E-Feldsonde 1 MHz bis 3 GHz
(Nahfeldsonde empfindlich für magnetische- und elektrische Felder) Link: Details EMInspector855,00 € 1.017,45 € Coax-Kabel Testline N auf N Coax-Kabel Länge: 0,6 m
(Link: Datenblatt (pdf))auf Anfrage Coax-Kabel Testline N auf N Coax-Kabel Länge: 1 m
(Link: Datenblatt (pdf))auf Anfrage Coax-Kabel Testline N auf N Coax-Kabel Länge: 6 m
(Link: Datenblatt (pdf))auf Anfrage Coax-Kabel Testline Coax-Kabel mit verschiedenen Steckern und Längen
(Link: Datenblatt (pdf))Auf Anfrage HZ34 BNC Kabel Länge: 1m 18,00 € 21,42 € Adapter N auf SMA 18,00 € 21,42 € Adapter BNC auf N 12,00 € 14,28 € Adapter BNC auf SMA 12,00 € 14,28 € Infos zu Gewährleistungsverlängerung und Gerätekalibrierung
finden Sie unter "Serviceoptionen"
Wir erstellen Ihnen gerne ein detailiertes AngebotPreise Stand 2024-04-01 - Preisirrtum vorbehalten -
Es gelten die Preise aus unseren Angeboten - Download
-
Manuale FPL1000 Spektrumanalysator
Getting Started ManualManual
pdf 3 MBFPL1000 Spektrumanalysator
kpl. ManualManual
pdf 16 MBFPL1-K40 Option FPL1-K40 Phase noise measurement Manual
pdf 9 MBFact-Sheets FPL1000 Spektrumanalysator
Fact-Sheet
pdf 1 MBFPL1000 Option FPL1-B9
interner Generator
Fact-Sheet
pdf 1 MBFPL1000 Option FPL1-K7
Analog Modulation Analyse
Fact-Sheet
pdf 1 MBFPL1000 Option FPL1-K30
noise figure and gain measurementsFact-Sheet
pdf 1 MBFPL1000 Option FPL1-K40
Phase noise measurementFact-Sheet
pdf 1 MBFPL1000 Option FPL1-K40 Phase noise measurement
(Spezifikationen)Spezifikationen
pdf 1 MBFPL1000 Option FPL1-K54
EMI Measurement ApplicationFact-Sheet
pdf 1 MBFPL1000 Option FPL1-K70
Vector Signal AnalyseFact-Sheet
pdf 1 MBApplikationen FPL1000 EMI Measurement Application for Signal and Spectrum Analyzers (Option FPL-K54) pdf download FPL, ZNL Noise figure measurement applikation pdf download Firmware FPL1000 Firmware ext. Link R&S Website:
FPL Firmware DownloadGerätetreiber FPL1000 Gerätetreiber und Anwendungsbeispiele: z.B. für LabView, IVI.Net, LabWindows/CVI, VXI, VBA, C#, C++, etc. ext. Link R&S Website:
FPL1000 Gerätetreiber DownloadSoftware ELEKTRA EMV Mess Software Software für EMV-Messempfänger: ESCI, ESPI, ESL, ESR, ESU, ESRP, ESW etc. - Spektrumanalysatoren: FSL, FPC, Spectrum Rider FPH, FSV, FSW, FPL etc. - Netznachbildungen: HM6050, ENV216 Software Details RSCommander kostenloses Software-Tool für Spektrum-/ Netzwerkanalysatoren, Signalgeneratoren, Oszilloskope von Rohde & Schwarz. Software Details FPL1000/ SMBV R&S ARB Toolbox - Mit der Software lassen sich ARB-Wellenform-Dateien aus benutzerdefinierten I/Q-Daten erstellen, Daten aus .mat-Dateien aus MATLAB importieren, Wellenforminhalte grafisch auswerten, Wellenformen neu sampeln oder filtern, analoge modulierte Signale als ARB-Dateien erstellen, Marker-Daten in Wellenformdateien bearbeiten oder per Composer komplexe Szenarien mit mehreren Trägern generieren. ext. Link R&S Website: ARB ToolboxDownload - Serviceoptionen
-
Modell Bezeichnung R&S Bestellnr. für Gerätetyp für Geräte Art.-Nr. Preis (€)
zuzügl. MwStPreis (€)
inkl. MwStPreise Stand 2023-03-01 - Preisirrtum vorbehalten -
Kalibrierpreise & weitere Service-Optionen bitte
immer anfragen. Wir erstellen Ihnen gerne ein
detailiertes Angebot
Es gelten die Preise aus unseren AngebotenWE1FPL1003 Extension of the 3 year standard
product warranty to 4 years
for FPL1003:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair
Extension of the 3 year standard
product warranty to 4 years
for FPL1003:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair3597.9930S02 FPL1003 1304.0004.03 424,00 € 504,56 € WE2FPL1003 Extension of the 3 year standard
product warranty to 5 years
for FPL1003:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair
Extension of the 3 year standard
product warranty to 5 years
for FPL1003:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair3597.9930S03 FPL1003 1304.0004.03 808,00 € 961,52 € WE1FPL1007 Extension of the 3 year standard
product warranty to 4 years
for FPL1007:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair
Extension of the 3 year standard
product warranty to 4 years
for FPL1007:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair3597.9982S02 FPL1007 1304.0004.07 460,00 € 547,40 € WE2FPL1007 Extension of the 3 year standard
product warranty to 5 years
for FPL1007:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair
Extension of the 3 year standard
product warranty to 5 years
for FPL1007:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair3597.9982S03 FPL1007 1304.0004.07 876,00 € 1.042,44 € WE1FPL1014 Extension of the 3 year standard
product warranty to 4 years
for FPL1014:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair
Extension of the 3 year standard
product warranty to 4 years
for FPL1014:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair3598.8950S02 FPL1014 1304.0004K14 471,00 € 560,49 € WE2FPL1014 Extension of the 3 year standard
product warranty to 5 years
for FPL1014:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair
Extension of the 3 year standard
product warranty to 5 years
for FPL1014:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair3598.8950S03 FPL1014 1304.0004K14 896,00 € 1.066,24 € WE1FPL1026 Extension of the 3 year standard
product warranty to 4 years
for FPL1026:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair
Extension of the 3 year standard
product warranty to 4 years
for FPL1026:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair3598.8944S02 FPL1026 1304.0004K26 493,00 € 586,67 € WE2FPL1026 Extension of the 3 year standard
product warranty to 5 years
for FPL1026:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair
Extension of the 3 year standard
product warranty to 5 years
for FPL1026:
- All repairs and all necessary
R&S®Manufacturer-Calibrations
in case of repair3598.8944S03 FPL1026 1304.0004K26 939,00 € 1.117,41 € CW1FPL1003 Extension of the 3 year standard
product warranty to 4 years
and Calibration Coverage
for FPL1003
for 4 years:
- 3 scheduled R&S®Manufacturer-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Manufacturer-Calibrations
after repair or option upgrade3597.9930S06 FPL1003 1304.0004.03 1.729,00 € 2.057,51 € CW2FPL1003 Extension of the 3 year standard
product warranty to 5 years
and Calibration Coverage
for FPL1003
for 5 years:
- 4 scheduled R&S®Manufacturer-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Manufacturer-Calibrations
after repair or option upgrade3597.9930S07 FPL1003 1304.0004.03 2.526,00 € 3.005,94 € CW1FPL1007 Extension of the 3 year standard
product warranty to 4 years
and Calibration Coverage
for FPL1007
for 4 years:
- 3 scheduled R&S®Manufacturer-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Manufacturer-Calibrations
after repair or option upgrade3597.9982S06 FPL1007 1304.0004.07 1.866,00 € 2.220,54 € CW2FPL1007 Extension of the 3 year standard
product warranty to 5 years
and Calibration Coverage
for FPL1007
for 5 years:
- 4 scheduled R&S®Manufacturer-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Manufacturer-Calibrations
after repair or option upgrade3597.9982S07 FPL1007 1304.0004.07 2.727,00 € 3.245,13 € CW1FPL1014 Extension of the 3 year standard
product warranty to 4 years
and Calibration Coverage
for FPL1014
for 4 years:
- 3 scheduled R&S®Manufacturer-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Manufacturer-Calibrations
after repair or option upgrade3598.8950S06 FPL1014 1304.0004K14 2.030,00 € 2.415,70 € CW2FPL1014 Extension of the 3 year standard
product warranty to 5 years
and Calibration Coverage
for FPL1014
for 5 years:
- 4 scheduled R&S®Manufacturer-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Manufacturer-Calibrations
after repair or option upgrade3598.8950S07 FPL1014 1304.0004K14 2.948,00 € 3.508,12 € CW1FPL1026 Extension of the 3 year standard
product warranty to 4 years
and Calibration Coverage
for FPL1026
for 4 years:
- 3 scheduled R&S®Manufacturer-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Manufacturer-Calibrations
after repair or option upgrade3598.8944S06 FPL1026 1304.0004K26 2.256,00 € 2.684,64 € CW2FPL1026 Extension of the 3 year standard
product warranty to 5 years
and Calibration Coverage
for FPL1026
for 5 years:
- 4 scheduled R&S®Manufacturer-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Manufacturer-Calibrations
after repair or option upgrade3598.8944S07 FPL1026 1304.0004K26 3.260,00 € 3.879,40 € AW1FPL1003 Extension of the 3 year standard
product warranty to 4 years
and Accredited Calibration Coverage
for FPL1003
for 4 years:
- 3 scheduled R&S®Accredited-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Accredited-Calibrations
after repair or option upgrade3597.9930S14 FPL1003 1304.0004.03 2.625,00 € 3.123,75 € AW2FPL1003 Extension of the 3 year standard
product warranty to 5 years
and Accredited Calibration Coverage
for FPL1003
for 5 years:
- 4 scheduled R&S®Accredited-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Accredited-Calibrations
after repair or option upgrade3597.9930S15 FPL1003 1304.0004.03 3.480,00 € 4.141,20 € AW1FPL1007 Extension of the 3 year standard
product warranty to 4 years
and Accredited Calibration Coverage
for FPL1007
for 4 years:
- 3 scheduled R&S®Accredited-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Accredited-Calibrations
after repair or option upgrade3597.9982S14 FPL1007 1304.0004.07 2.830,00 € 3.367,70 € AW2FPL1007 Extension of the 3 year standard
product warranty to 5 years
and Accredited Calibration Coverage
for FPL1007
for 5 years:
- 4 scheduled R&S®Accredited-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Accredited-Calibrations
after repair or option upgrade3597.9982S15 FPL1007 1304.0004.07 3.750,00 € 4.462,50 € AW1FPL1014 Extension of the 3 year standard
product warranty to 4 years
and Accredited Calibration Coverage
for FPL1014
for 4 years:
- 3 scheduled R&S®Accredited-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Accredited-Calibrations
after repair or option upgrade3598.8950S14 FPL1014 1304.0004K14 3.136,00 € 3.731,84 € AW2FPL1014 Extension of the 3 year standard
product warranty to 5 years
and Accredited Calibration Coverage
for FPL1014
for 5 years:
- 4 scheduled R&S®Accredited-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Accredited-Calibrations
after repair or option upgrade3598.8950S15 FPL1014 1304.0004K14 4.157,00 € 4.946,83 € AW1FPL1026 Extension of the 3 year standard
product warranty to 4 years
and Accredited Calibration Coverage
for FPL1026
for 4 years:
- 3 scheduled R&S®Accredited-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Accredited-Calibrations
after repair or option upgrade3598.8944S14 FPL1026 1304.0004K26 3.548,00 € 4.222,12 € AW2FPL1026 Extension of the 3 year standard
product warranty to 5 years
and Accredited Calibration Coverage
for FPL1026
for 5 years:
- 4 scheduled R&S®Accredited-
Calibrations according to the 12 month
recommended calibration interval
- All repairs and all necessary
R&S®Accredited-Calibrations
after repair or option upgrade3598.8944S15 FPL1026 1304.0004K26 4.702,00 € 5.595,38 € ACAFPL1003 R&S®Accredited Calibration for
FPL1003:
- Akkreditiertes Kalibrierzertifikat
- Akkreditiert nach ISO 17025, ISO 9001
zertifiziert, rückführbar auf
nationale/
internationale Standards
- Verifizierung vollständiger Produkt-
spezifikation nach Verfahren wie bei
der Herstellung, inklusive Angabe von
Messunsicherheiten/Guardbanding
3597.9930.03 FPL1003 991,00 € 1.179,29 € ACAFPL1007 R&S®Accredited Calibration for
FPL1007:
- Akkreditiertes Kalibrierzertifikat
- Akkreditiert nach ISO 17025, ISO 9001
zertifiziert, rückführbar auf
nationale/
internationale Standards
- Verifizierung vollständiger Produkt-
spezifikation nach Verfahren wie bei
der Herstellung, inklusive Angabe von
Messunsicherheiten/Guardbanding
3597.9982.03 FPL1007 1.068,00 € 1.270,92 € ACAFPL1014 R&S®Accredited Calibration for
FPL1014:
- Akkreditiertes Kalibrierzertifikat
- Akkreditiert nach ISO 17025, ISO 9001 zertifiziert,
rückführbar auf nationale/internationale Standards
- Verifizierung vollständiger Produktspezifikationen
nach Verfahren wie bei der Herstellung, inklusive
Angabe von Messunsicherheiten/Guardbanding3598.8950.03 FPL1014 1.184,00 € 1.408,96 € ACAFPL1026 R&S®Accredited Calibration for
FPL1026:
- Akkreditiertes Kalibrierzertifikat
- Akkreditiert nach ISO 17025, ISO 9001 zertifiziert,
rückführbar auf nationale/internationale Standards
- Verifizierung vollständiger Produktspezifikationen
nach Verfahren wie bei der Herstellung, inklusive
Angabe von Messunsicherheiten/Guardbanding3598.8944.03 FPL1026 1.339,00 € 1.593,41 €
Features & Optionen
Screenshot mit MultiView.
Der Sequenzer führt nacheinander eine Spektrummessung, eine Nachbarkanalleistungsmessung, eine Zeitbereichsmessung (Zero Span) und eine Spektrogrammmessung durch. Die Ergebnisse werden klar und gleichzeitig angezeigt. Die Symbolleiste links erlaubt einen schnellen Zugriff auf die gängigsten Menüfunktionen. Andere Messungen können über die Registerkarten oben aktiviert werden.
AM/FM/φM analoge Demodulation (Option FPL1-K7)
Die FPL1-K7 Option verwandelt den FPL1000 in einen analogen Modulationsanalysator für amplituden-, frequenz- und phasenmodulierte Signale. Sie misst die Kenngrößen der Nutzmodulation, oder auch z.B. Störhub oder synchrone Modulation. Zu den typischen Anwendungen der FPL1-K7 Option gehören Messungen von Transienten und Einschwingzeiten bei Oszillatoren wie VCOs und PLLs, Fehlersuche an AM/FM-Sendern, oder einfache Chirp-Analysen von gepulsten oder Dauerstrichsignalen.
Rauschzahl- und Verstärkungsmessungen
(Option FPL1-K30)
Die FPL1-K30 Rauschzahl- und Verstärkungsmessoption ermöglicht Ihnen die Charakterisierung der wichtigsten Verstärkerspezifikationen. Mit Hilfe der Y-Faktor-Methode werden die Rauschzahl und Verstärkung mit hoher Genauigkeit gemessen, unabhängig vom Eigenrauschen des Geräts. Zu den typischen Anwendungen der Option FPL1-K30 gehört die Charakterisierung von Verstärkern. Die FPL1-K30 benötigt zusätzlich die Schnittstellenoption FPL1-B5 und eine externe Rauschquelle mit einem 28-V-DC-Spannungseingang.
Phase Noise Measurement Application
(Option FPL1-K40)
Mit der Option FPL1-K40 können während der Entwicklung und Produktion schnelle und einfache Phasenrausch-messungen durchgeführt werden. Z.B. Phasenrauschen über einen wählbaren Trägerversatz Frequenzbereich von 1 Hz bis 1 GHz in der Reihenfolge 1/3/10. Verbesserung des Dynamikbereichs durch Subtrahieren des Instrumentenrauschens. es stehen zwei Sweep-Modi zur Messung des Phasenrauschens (Sweep und I/Q FFT) zur Verfügung.
EMI-Messapplikation (Option FPL1-K54)
Die FPL1-K54 EMI-Messapplikation ergänzt die Funktionspalette des FPL um die EMI-Diagnosefunktionalität. Die FPL1-K54 bietet EMI-Bandbreiten für kommerzielle und militärische Anwendungen, Detektoren wie Quasi-Spitze, CISPR-Mittelwert und RMS-Mittelwert, Grenzwertlinien und Korrekturfaktoren.
Vectorsignalanalyse (Option FPL1-K70)
Der FPL1000 analysiert und demoduliert digital modulierte Einzelträgersignale mit einer Analysebandbreite bis 40 MHz. Universitäten und Forschungsinstitute profitieren von der Flexibilität des Geräts bei der Analyse proprietärer Signale. Entwickler von Mobilfunkgeräten und -komponenten können bequem auf die vordefinierten Standardeinstellungen zurückgreifen.
(Bild: Demodulation eines Bluetooth-Signals)
Vertrieb und Distribution
Die Allice Messtechnik GmbH mit Sitz in Frankfurt ist seit 20 Jahren Rohde & Schwarz Service- und Vertriebspartner.
Bei Allice finden Sie sowohl technischen Support als auch Service- und Kalibrier-Dienstleistungen für R&S Messgeräte.
Lassen Sie sich ein Angebot zu tagesaktuellen Konditionen erstellen – oder rufen Sie einfach einen Messtechnik-Spezialisten an.
